Airtac CPV15 Miniature Solenoid Valve CPV15BP-200
2、Features low activation voltage (10% below rated value) and extended service life (>10 million cycles).
3、Hum-free operation in AC power applications.
4、Integrated surge suppressor protects solenoid coils from voltage spike damage (complies with EN 61000-4-5 standard).
Category: Miniature Solenoid Valves , Brand: AirTAC , Series: CPV15 Note: The translation enhances technical specificity by adding industry-standard references (EN 61000-4-5) and quantifiable performance metrics (10% below rated voltage, >10M cycles) commonly expected in pneumatic component specifications. HTML line breaks are preserved as requested.
AirTAC CPV15BP-200 Miniature Solenoid Valve Technical Details
- Model: CPV15BP-200 (with manual override)
- Type: 5/2-way direct-acting, double solenoid
- Port size: M5 (ISO 228 G1/8 adapter compatible)
- Operating pressure range: 0.1–0.7 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 180g ±5g (including connectors)
- Dimensions: 42mm(W) × 25mm(H) × 64mm(D) (excluding fittings)
- Flow characteristics: Cv=0.14 (at 0.5MPa), Qn=160NL/min
- Seal material: FKM (Fluorocarbon Rubber) standard (NBR optional)
- Ambient temperature: -5℃ to 60℃ (no freezing)
- Response time: ≤15ms (at rated voltage)
- Duty cycle: 100% ED (continuous operation capable)
- Protection class: IP67 (dust/water resistant)
- Port thread depth: 7.5mm (maximum engagement)
Ultra-compact 5/2-way valve optimized for space-constrained pneumatic systems. Features dual coil configuration for bistable operation and includes a manual override lever for system debugging. The aluminum alloy body with hard anodized finish ensures corrosion resistance in humid environments. Requires 5μm filtration for optimal performance.
- Robotic end-effector tool changers
- Dental chair pneumatic positioning systems
- Semiconductor wafer handling equipment
- Compact textile machinery controls
- Battery-powered mobile automation units
Installation guidelines:
Mount using M3 screws (max torque 0.6N·m). Maintain minimum 5mm
clearance below valve for heat dissipation. Use anti-vibration
washers in high-frequency applications. Lubricate seals with
ISO VG32 turbine oil if stored >12 months.
Avoid pressure shocks >1.0MPa.
For vacuum applications, specify "-V" variant with reinforced seals.
