Airtac F-SC-TC Trunnion Bracket F-SC160TC
$116.02
Regular price
$123.52
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
F-SC160TC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Accessories
Brand: AirTAC
Series: F-SC-TC Center Trunnion Bracket
The AirTAC F-SC-TC Series Center Trunnion Bracket is an engineered mounting solution designed for precision alignment and load distribution in pneumatic cylinder applications. Featuring reinforced trunnion geometry with ISO standardized mounting dimensions, this accessory ensures optimal moment resistance during reciprocating motion cycles. The bracket's CNC-machined interface surfaces provide superior parallelism and perpendicularity tolerances, while through-hardened mounting holes maintain dimensional stability under dynamic loading conditions. Compatible with ISO 15552/VDMA 24562 cylinder profiles.
Installation guidelines:
Apply medium-strength thread locker (Loctite 243 recommended) on shaft threads.
Lubricate bearing with ISO VG32 hydraulic oil before initial operation.
Maximum radial load: 120N (continuous), 250N (peak).
Brand: AirTAC
Series: F-SC-TC Center Trunnion Bracket
The AirTAC F-SC-TC Series Center Trunnion Bracket is an engineered mounting solution designed for precision alignment and load distribution in pneumatic cylinder applications. Featuring reinforced trunnion geometry with ISO standardized mounting dimensions, this accessory ensures optimal moment resistance during reciprocating motion cycles. The bracket's CNC-machined interface surfaces provide superior parallelism and perpendicularity tolerances, while through-hardened mounting holes maintain dimensional stability under dynamic loading conditions. Compatible with ISO 15552/VDMA 24562 cylinder profiles.
AirTAC F-SC160TC Mid-Eyelet Bracket Specifications
- Model: F-SC-TC series (F-SC160TC)
- Type: Pivot bracket with threaded shaft
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Black anodized (15-20μm)
- Compatible cylinder bore: Φ16mm
- Shaft thread: M6×1.0 (ISO metric fine)
- Bearing type: Needle roller bearing (HK0608)
- Rotation angle: ±90° adjustable
- Mounting hole spacing: 32±0.1mm (horizontal), 18±0.1mm (vertical)
- Fastening torque: 1.2-1.5N·m (threaded connections)
- Temperature range: -20℃ to 120℃
- Weight: 84g ±2g
- Dimensions: 50mm(L) × 32mm(W) × 25mm(H)
- Corrosion resistance: 96hrs salt spray test passed
Precision-machined pivot bracket with integrated needle bearing, designed for smooth rotational motion in compact pneumatic systems. Features hardened steel shaft (HRC 45-50) and anti-corrosion coating. Includes stainless steel mounting hardware (SUS304).
Typical Applications:
- Rotary actuator linkages in packaging machinery
- Pneumatic gripper articulation joints
- Conveyor diverter arm pivots
- Automated door hinge mechanisms
- Textile machinery tensioning systems
Installation guidelines:
Apply medium-strength thread locker (Loctite 243 recommended) on shaft threads.
Lubricate bearing with ISO VG32 hydraulic oil before initial operation.
Maximum radial load: 120N (continuous), 250N (peak).
| Property | Property Value |
|---|---|
| sku | F-SC160TC |
