Airtac GAC F.R.L. Unit GAC20006ALN
The AirTAC Airtac GAC F.R.L. Unit GAC20006ALN is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ALN
Delivering cleaned, regulated and lubricated air for small pneumatic duties, this AirTAC unit combines a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port and 750 g weight place it in the compact GAC200 size class, making it ideal for feeding a single actuator or a small jig where panel space is tight. This specific variant features a 40 um element and operates on the lower pressure range of 0.15-0.4 MPa (20-58 psi). Because the N appears after the port code, no pressure gauge is supplied from the factory; a 1/8in gauge connection is available if you need to add instrumentation later.
The build order routes incoming air through the filter first, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so it never fouls the regulator seat. Condensate is managed by an automatic drain fitted to the 25 cc bowl, clearing liquid without an operator on site. The 36 cc oil bowl sets the lubrication refill interval for this size class. If your downstream line must remain strictly oil-free, omit the lubricator entirely and choose a dedicated filter-regulator instead.
Airtac GAC F.R.L. Unit GAC20006ALN Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ALN |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ALN
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ALN Is Used
Small Assembly Jigs
Feeds filtered and lubricated air to low-pressure clamping cylinders on benchtop electronics assembly jigs.
Lab Pneumatic Stations
Conditions supply air for sensitive laboratory test fixtures requiring a strict 0.15-0.4 MPa operating range.
Single Actuator Tools
Prepares air for individual pneumatic actuators on light-duty handheld tools where a compact 1/8in port is sufficient.
Is the Airtac GAC F.R.L. Unit GAC20006ALN the Right Air-Prep Unit?
Choose this GAC200 model for low-pressure applications requiring a 0.15-0.4 MPa (20-58 psi) operating range, rather than the standard 0.15-0.9 MPa type. The PC bowl and 40 um element suit general factory air, while the automatic drain is decisive for unattended or wet lines. Since no gauge is included, the set pressure cannot be read without adding one to the 1/8in connection. If your machine needs a higher flow capacity, stepping up to the GAC300 body increases the plotted flow envelope to 3000 L/min at 0.7 MPa inlet, compared to the 1750 L/min envelope of this GAC200. Replacement spares follow the body and port directly: GAF200-06, GAR200-06 and GAL200-06. Keep in mind that 0.4 MPa is only 44% of the standard 0.9 MPa ceiling, so select this lower-pressure variant only if the equipment will never require higher settings.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ALN FAQ
This F.R.L. combination operates on the lower pressure range of 0.15-0.4 MPa (20-58 psi). It has a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. The drain bowl holds 25 cc and the oil bowl holds 36 cc, with a total weight of 750 g. The recommended lubricant is ISO VG 32.
The N at the end of the model code indicates that no circular gauge is supplied. If you need to monitor the outlet pressure, the body features a 1/8in gauge connection that allows you to install a separate PT-threaded gauge reading in MPa/psi.
