Airtac GAC F.R.L. Unit GAC20006ALNK
The AirTAC Airtac GAC F.R.L. Unit GAC20006ALNK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ALNK
Supplying a single actuator or small jig demands precisely conditioned air, which this pre-assembled filter, regulator and lubricator combination delivers through a 1/8in port. Air passes through the 40 um filter first, then enters the regulator set to the lower 0.15-0.4 MPa (20-58 psi) range, before oil mist is introduced by the lubricator downstream of the pressure seat. The three units arrive aligned on a single L-shape bracket with quick mounting clamps, eliminating inter-unit tubing and the leak paths they create.
Weighing 750 g, this body pairs a 25 cc condensate bowl with a 36 cc oil reservoir. The automatic drain clears accumulated water without an operator, a vital feature for unattended lines. No gauge is supplied, but the body features a 1/8in gauge connection if you need to add instrumentation later. This configuration also includes a reverse-flow (reflux) valve, which the catalogue shows as a separate pneumatic symbol with details on its own page.
Airtac GAC F.R.L. Unit GAC20006ALNK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ALNK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ALNK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ALNK Is Used
Small Pneumatic Jigs
Feeds filtered, regulated and lubricated air to single-actuator bench jigs operating at low pressure.
Instrument Air Lines
Conditions supply for delicate low-force pneumatic probes and gauges requiring a 0.15-0.4 MPa range.
Lab Automation
Prepares clean, oil-misted air for small-scale laboratory pick-and-place actuators on unattended test benches.
Is the Airtac GAC F.R.L. Unit GAC20006ALNK the Right Air-Prep Unit?
Choose this lower-pressure type for equipment strictly limited to 0.15-0.4 MPa (20-58 psi); if the machine may ever need more, the standard 0.15-0.9 MPa version is the correct choice. The 40 um element suits general pneumatic duty, while the fitted automatic drain suits wet environments. Because the lubricator adds oil mist downstream, select a filter-regulator instead if the line must remain oil-free. Should a component fail, the assembly splits into separately orderable spares: GAF200-06, GAR200-06 and GAL200-06. The catalogue flow curve for the GAC200 is plotted to 1750 L/min at 0.7 MPa inlet, which is about 58% of the GAC300's 3000 L/min envelope. The lower-pressure type tops out at 0.4 MPa, which is 44% of the standard 0.9 MPa ceiling.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ALNK FAQ
This lower-pressure F.R.L. combination regulates air to 0.15-0.4 MPa (20-58 psi). It has a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The operating temperature is -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, weighs 750 g, and uses ISO VG 32 lubricant.
The N in the model code indicates no gauge is supplied. The body has a 1/8in gauge connection, allowing you to install a separate PT-threaded gauge reading in MPa/psi to monitor the 0.15-0.4 MPa set pressure.
