Airtac GAC F.R.L. Unit GAC20006ALNW
The AirTAC Airtac GAC F.R.L. Unit GAC20006ALNW is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ALNW
Delivering cleaned, regulated and lubricated air for small pneumatic duties, the AirTAC GAC20006ALNW integrates a filter, regulator and lubricator on a single L-shape bracket. This assembly features a 1/8in port, a 5 um element for fine particle capture, and operates across a 0.15-0.4 MPa (20-58 psi) lower pressure range. Weighing 750 g, it is sized for single actuators rather than plant headers.
The build sequence passes air through the filter first, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat stays clean. An automatic drain clears condensate from the 25 cc bowl without an operator, which is decisive for unattended jigs. No gauge is supplied, but a 1/8in gauge connection is provided if you need to add one later.
Airtac GAC F.R.L. Unit GAC20006ALNW Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ALNW |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ALNW
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ALNW Is Used
Micro-Pneumatic Clamping
Feeds clean, finely filtered and lubricated air to low-pressure clamping cylinders on delicate electronics assembly jigs.
Lab Analytical Tools
Conditions air for small-scale actuators in laboratory automation where a 5 um element protects sensitive valves from fine particulates.
Benchtop Pick-and-Place
Supplies metered oil mist and stable low pressure to miniature grippers on benchtop pick-and-place robots using 1/8in fittings.
Is the Airtac GAC F.R.L. Unit GAC20006ALNW the Right Air-Prep Unit?
This unit uses a PC bowl and a 5 um element, trapping far finer particles than the standard 40 um grade for precision valves, at the cost of more frequent element service. The automatic drain suits wet lines, and because the thread is PT, a fitted gauge would read MPa/psi. If the downstream line must stay oil-free, choose a filter-regulator instead and omit the lubricator. Spares are ordered separately as GAF200-06, GAR200-06 and GAL200-06.
The 0.4 MPa ceiling is about 44% of the Standard type's 0.9 MPa maximum, so confirm your application never requires more pressure before specifying this lower-pressure variant.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ALNW FAQ
This lower-pressure type operates at 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). It has a 5 um element, a 25 cc drain bowl, a 36 cc oil bowl, and weighs 750 g. The temperature range is -5 to 70 C, and the recommended lubricant is ISO VG 32.
No gauge is supplied with this unit. The body features a 1/8in gauge connection, allowing you to install a separate gauge if you need to monitor the 0.15-0.4 MPa outlet pressure.
