Airtac GAC F.R.L. Unit GAC20006ALNWK
The AirTAC Airtac GAC F.R.L. Unit GAC20006ALNWK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ALNWK
Delivering cleaned, regulated and lubricated air for compact pneumatics, this AirTAC F.R.L. combination integrates a filter, regulator and lubricator on a single L-shape bracket. The 1/8in ported body weighs 750 g and houses a 5 um element to trap fine particulates before they reach sensitive valves. Because the lubricator sits last in the airflow path, oil mist is introduced downstream of the regulator seat, preventing fouling of the pressure-control mechanism.
Configured for low-pressure duties, the unit regulates between 0.15-0.4 MPa (20-58 psi) and includes an automatic drain that evacuates the 25 cc condensate bowl without operator intervention. No pressure gauge is supplied, but a 1/8in connection allows one to be added if visual monitoring is required. The assembly also features a reverse-flow (reflux) valve, which the catalogue depicts as a distinct pneumatic symbol with details on its own page.
Airtac GAC F.R.L. Unit GAC20006ALNWK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ALNWK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ALNWK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ALNWK Is Used
Micro-Assembly Jigs
Feeds low-pressure air to small grippers handling delicate electronics where a 5 um element prevents dust from clogging tiny internal passages.
Laboratory Actuators
Provides stable 0.15-0.4 MPa control for sensitive pneumatic test rigs, with the automatic drain clearing condensate between unattended cycles.
Pick-and-Place Heads
Lubricates miniature suction cups and cylinders on benchtop machines, ensuring smooth cycling without over-pressurizing the lightweight mechanisms.
Is the Airtac GAC F.R.L. Unit GAC20006ALNWK the Right Air-Prep Unit?
This assembly suits single actuators or small jigs requiring precise low-pressure control. If a machine might eventually need more than 0.4 MPa, the L type is the wrong choice and the standard S type should be selected instead. The 5 um element provides finer filtration than the standard 40 um grade, ideal for instrument air, though it requires more frequent replacement. Should the line need to stay completely oil-free, omit the lubricator and choose a separate filter-regulator. For maintenance, the individual components are orderable as GAF200-06, GAR200-06 and GAL200-06. Stepping up to the GAC300 body increases the plotted flow envelope from 1750 to 3000 L/min at 0.7 MPa inlet, an increase of roughly 1.7x for higher demand. Keep in mind the 0.4 MPa upper limit of this L type is about 44% of the standard 0.9 MPa ceiling.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ALNWK FAQ
This lower-pressure type unit regulates from 0.15-0.4 MPa (20-58 psi) and has a maximum pressure of 1.0 MPa (145 psi) with a 1.5 MPa (215 psi) proof pressure. It operates from -5 to 70 C, uses a 25 cc drain bowl and a 36 cc oil bowl, and weighs 750 g. The recommended lubricant is ISO VG 32.
The N in the product code signifies no gauge is supplied. The body features a 1/8in gauge connection, allowing operators to install a compatible gauge reading in MPa/psi to match the default PT thread if visual pressure verification is needed.
