Airtac GAC F.R.L. Unit GAC20006ALW
The AirTAC Airtac GAC F.R.L. Unit GAC20006ALW is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ALW
Delivering cleaned, regulated and lubricated air for pneumatic setups, this AirTAC unit integrates a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port pairs with a 5 um element to trap fine particles, while the lower-pressure type restricts the operating range to 0.15-0.4 MPa (20-58 psi). A circular gauge reading MPa/psi is fitted for the default PT thread.
Air passes through the filter, then the regulator, and finally the lubricator so oil mist is added downstream of the regulator seat. The automatic drain clears condensate without an operator, which is decisive for unattended or wet lines. If the downstream line must stay oil-free, omit the lubricator and choose a filter-regulator instead.
Airtac GAC F.R.L. Unit GAC20006ALW Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ALW |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006ALW
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ALW Is Used
Micro-Actuator Jigs
Feeds single small-bore cylinders in bench-top assembly jigs where precise low-pressure actuation is required.
Lab Pneumatics
Conditions air for sensitive laboratory gas valves needing fine 5 um filtration and stable low-pressure delivery.
Pick-and-Place
Supplies oil-misted air to small gripper units on light-duty pick-and-place robots operating continuously.
Is the Airtac GAC F.R.L. Unit GAC20006ALW the Right Air-Prep Unit?
This 750 g assembly needs a proper panel or frame mount rather than support from the tubing. The 25 cc condensate bowl and 36 cc oil bowl drive the service interval, meaning someone must attend the unit relatively often compared to larger bodies. The 5 um element traps far finer particles for precision valves or instrument air at the cost of more frequent element service. Spares are ordered separately as GAF200-06, GAR200-06 and GAL200-06. Choosing the L type tops out at 0.4 MPa, which is 44% of the Standard type's 0.9 MPa ceiling.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ALW FAQ
It operates at 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It has a 25 cc drain bowl, a 36 cc oil bowl, weighs 750 g, and uses ISO VG 32 lubricant.
The 5 um element traps far finer particles than the standard 40 um grade, making it suitable for precision valves or instrument air, though it requires more frequent service. The automatic drain clears condensate without an operator, which is ideal for unattended or wet lines.
