Airtac GAC F.R.L. Unit GAC20006ALWK
The AirTAC Airtac GAC F.R.L. Unit GAC20006ALWK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ALWK
Delivering cleaned, regulated and lubricated air for small pneumatics, this AirTAC assembly integrates a filter, regulator and lubricator on a single L-shape bracket. It features a 1/8in port, a 5 um element and a lower pressure range of 0.15-0.4 MPa (20-58 psi). The 750 g mass suits compact jigs where panel mounting is preferred over tubing support.
Air passes through the filter, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat never fouls. A circular gauge is fitted, reading MPa/psi for the default PT thread. This configuration includes a reverse-flow (reflux) valve, which the catalogue shows as a separate pneumatic symbol with details on its own page.
Airtac GAC F.R.L. Unit GAC20006ALWK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ALWK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006ALWK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ALWK Is Used
Micro-Assembly Jigs
Feeds low-pressure air to delicate pick-and-place nozzles handling surface-mounted electronics.
Laboratory Actuators
Conditions air for small bore cylinders driving fluid dispensing pumps in benchtop environments.
Pneumatic Hand Tools
Supplies a fine 5 um filtered oil mist to precision air screwdrivers on a light assembly line.
Is the Airtac GAC F.R.L. Unit GAC20006ALWK the Right Air-Prep Unit?
This unit uses a PC bowl and an automatic drain that clears condensate without an operator, a decisive feature for unattended lines. The 5 um element traps far finer particles than the standard 40 um grade, suiting precision valves at the cost of more frequent element service. If the machine requires oil-free output, omit the lubricator and choose a filter-regulator instead. Spares are available as GAF200-06, GAR200-06 and GAL200-06.
The catalogue flow curve for the GAC200 is plotted to 1750 L/min at 0.7 MPa inlet, roughly 29% of the GAC300's 3000 L/min envelope, making it best for single actuators. Because this L type tops out at 0.4 MPa, it operates at about 44% of the Standard type's 0.9 MPa ceiling.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ALWK FAQ
It operates at 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C, the drain bowl holds 25 cc, the oil bowl holds 36 cc, the recommended lubricant is ISO VG 32, and the unit weighs 750 g.
The automatic drain clears condensate without an operator, ideal for wet lines. The reflux valve is fitted as an ordering difference, shown as a separate pneumatic symbol in the catalogue, though its specific function must be confirmed from datasheet.
