Airtac GAC F.R.L. Unit GAC20006ASN
The AirTAC Airtac GAC F.R.L. Unit GAC20006ASN is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ASN
Delivering cleaned, regulated and lubricated air for single actuators, this AirTAC combination mounts a filter, regulator and lubricator on one L-shape bracket. The 1/8in port feeds a standard 0.15-0.9 MPa (20-130 psi) working range, while the 40 um element captures solid particles before they reach downstream valves.
Because the letter N follows the port code, no pressure gauge is supplied; operators can add one via the 1/8in gauge connection. The automatic drain actively clears the 25 cc condensate bowl without an operator, and the 36 cc oil bowl supplies a steady mist to moving parts.
Airtac GAC F.R.L. Unit GAC20006ASN Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ASN |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ASN
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ASN Is Used
Small Pneumatic Jigs
Feeds single-acting cylinders in benchtop assembly jigs where a compact 1/8in port and 750 g mass keep the footprint minimal.
Air Power Tools
Prepares air for small handheld grinders by removing 40 um particles and injecting a controlled oil mist for rotor longevity.
Lab Automation
Conditions supply for test fixtures, relying on the automatic drain to empty the 25 cc bowl during unattended overnight cycles.
Is the Airtac GAC F.R.L. Unit GAC20006ASN the Right Air-Prep Unit?
Choose this 750 g assembly for light-duty jigs where space is tight, stepping up to the GAC300 if you need a larger 60 cc drain bowl. The PC bowl suits general plant air, and the automatic drain is ideal for unattended lines. Since the lubricator adds oil mist downstream of the regulator, select a separate filter-regulator if your process demands oil-free air. Replacement spares share the 200-06 suffix: GAF200-06, GAR200-06 and GAL200-06. Remember that the 1.0 MPa maximum supply leaves only about 0.1 MPa of headroom above the 0.9 MPa standard setting.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ASN FAQ
It operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, a 40 um element, uses ISO VG 32 lubricant, and weighs 750 g.
The N after the port code indicates no gauge is supplied. You can install your own circular gauge using the 1/8in gauge connection on the body, allowing you to choose a specific PT thread scale reading in MPa/psi.
