Airtac GAC F.R.L. Unit GAC20006ASNK
The AirTAC Airtac GAC F.R.L. Unit GAC20006ASNK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ASNK
Delivering cleaned, regulated and lubricated air for single actuators, this AirTAC F.R.L. combination integrates a filter, regulator and lubricator on a shared L-shape bracket. The 1/8in port pairs with a standard 0.15-0.9 MPa (20-130 psi) operating range and a 40 um element. Because the lubricator sits downstream of the regulator, the added oil mist never fouls the pressure-control seat.
This configuration uses a PC bowl and an automatic drain that empties the 25 cc condensate sump without operator input. No gauge is supplied, but a 1/8in connection is provisioned if you need to add one. The reverse-flow (reflux) valve is fitted, shown in the catalogue as a separate pneumatic symbol with details on its own page.
Airtac GAC F.R.L. Unit GAC20006ASNK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ASNK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ASNK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ASNK Is Used
Small Pneumatic Jigs
Feeds clean, lubricated air at a stable pressure to single-actuator clamping jigs on benchtop assembly benches.
Lab Pick-and-Place
Conditions supply air for low-flow laboratory pick-and-place robots using 1/8in fittings and 40 um filtration.
Benchtop Tooling
Prepares air for miniature air motors and precision grinders where an automatic drain prevents moisture buildup.
Is the Airtac GAC F.R.L. Unit GAC20006ASNK the Right Air-Prep Unit?
Choose this 750 g assembly for small jigs where space is tight, stepping up to the GAC300 if you need a larger 60 cc drain bowl. The automatic drain suits wet or unattended lines, while the missing gauge means set pressure cannot be read without adding a 1/8in accessory later. If the downstream line must stay oil-free, choose a filter-regulator instead and omit the lubricator. Spares follow the body-port suffix exactly: GAF200-06, GAR200-06 and GAL200-06. The catalogue flow curve for the GAC200 is plotted to 1750 L/min at 0.7 MPa inlet, which is roughly 29% of the GAC300's 3000 L/min envelope. Remember that max supply is 1.0 MPa and the Standard type regulates to 0.9 MPa, so there is only about 0.1 MPa of headroom above the top setting.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ASNK FAQ
This model operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, a 40 um element, and weighs 750 g. The recommended lubricant is ISO VG 32.
The N in the ordering code indicates no gauge is supplied. The body has a 1/8in gauge connection, so you must add a gauge separately to read the set pressure. The unit also includes a reverse-flow (reflux) valve, detailed on its own catalogue page.
