Airtac GAC F.R.L. Unit GAC20006ASNW
The AirTAC Airtac GAC F.R.L. Unit GAC20006ASNW is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ASNW
Delivering cleaned, regulated and lubricated air for single actuators, the GAC20006ASNW is a compact F.R.L. combination built around a 1/8" port. It pairs a 5 um filter, a pressure regulator and a lubricator on one L-shape bracket. The standard type regulates from 0.15-0.9 MPa (20-130 psi), while the 5 um element traps far finer particles than the default 40 um grade, making it ideal for sensitive pneumatic instrumentation.
Because the letter N follows the port code, no pressure gauge is supplied from the factory; operators can add one via the 1/8" gauge connection. The automatic drain clears condensate from the 25 cc bowl without manual intervention. Air passes through the filter first, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat never fouls.
Airtac GAC F.R.L. Unit GAC20006ASNW Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ASNW |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ASNW
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ASNW Is Used
Micro-Pneumatic Clamping
Feeds clean, lubricated air at a stable pressure to small precision clamping cylinders used in electronics assembly jigs.
Laboratory Air Tools
Conditions supply for delicate benchtop air tools and lab equipment, where the 5 um element protects internal passages from fine particulate ingress.
Single-Actuator Stations
Prepares air for individual linear actuators on standalone test fixtures, utilizing the automatic drain to handle condensate in unattended setups.
Is the Airtac GAC F.R.L. Unit GAC20006ASNW the Right Air-Prep Unit?
This 750 g assembly is the smallest in the GAC range, offering a 25 cc condensate bowl and a 36 cc oil reservoir. Stepping up to the GAC300 increases the oil capacity to 98 cc and extends the catalogue flow curve to 3000 L/min at 0.7 MPa inlet, compared to the 1750 L/min envelope plotted for this GAC200. If your downstream line must remain completely oil-free, omit the lubricator and choose a dedicated filter-regulator instead. Should a component fail, you can order spares individually using the GAF200-06, GAR200-06 and GAL200-06 codes. Keep in mind that the 1.0 MPa maximum supply leaves only about 0.1 MPa of headroom above the 0.9 MPa standard setting, so plan your inlet pressure carefully if you need maximum output.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ASNW FAQ
This standard type unit operates at 0.15-0.9 MPa (20-130 psi) with a maximum pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). It functions in temperatures from -5 to 70 C, features a 25 cc drain bowl and a 36 cc oil bowl, weighs 750 g, and uses ISO VG 32 lubricant.
The N in the ordering code indicates that no circular gauge is supplied. To read the set pressure, you must install your own gauge into the 1/8" gauge connection on the regulator body.
