Airtac GAC F.R.L. Unit GAC20006ASNWK
The AirTAC Airtac GAC F.R.L. Unit GAC20006ASNWK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ASNWK
Delivering cleaned, regulated and lubricated air for compact pneumatic setups, this AirTAC combination pre-assembles a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port suits single actuators or small jigs, and the 5 um element captures fine particles for sensitive instrumentation. Because the lubricator sits last in the sequence, oil mist is introduced downstream of the regulator seat, preventing fouling of the internal pressure control.
This specific configuration omits the pressure gauge to save space, though a 1/8in connection remains if you need to add one later. The automatic drain clears condensate from the 25 cc bowl without operator intervention, which is decisive for unattended or wet lines. A reverse-flow (reflux) valve is fitted, shown in the catalogue as a separate pneumatic symbol, and the unit weighs just 750 g.
Airtac GAC F.R.L. Unit GAC20006ASNWK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ASNWK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006ASNWK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ASNWK Is Used
Micro-Assembly Jigs
Feeds single small-bore cylinders in electronics pick-and-place machines where a 5 um element protects tiny valve clearances.
Laboratory Actuators
Conditions air for benchtop pneumatic test rigs, with the automatic drain keeping the 25 cc bowl empty during unattended overnight cycles.
Desktop Tooling
Supplies oil-misted air to miniature air motors in dental or jeweller bench tools, fitting within tight 750 g mounting frames.
Is the Airtac GAC F.R.L. Unit GAC20006ASNWK the Right Air-Prep Unit?
Choose this 1/8in body for light-duty tasks, stepping up to the GAC300 if your duty point exceeds the 1750 L/min plotted flow envelope at 0.7 MPa inlet. The PC bowl handles standard -5 to 70 C environments, while the 5 um element trades a shorter service life for high protection of precision valves. If the downstream line must stay oil-free, omit the lubricator and choose a separate filter-regulator instead. Spares follow the GAF200-06, GAR200-06 and GAL200-06 codes. Note that the 1.5 MPa (215 psi) proof pressure provides a 1.5x burst-test margin above the 1.0 MPa maximum, but this is not permission to run above 1.0 MPa.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ASNWK FAQ
This model operates at 0.15-0.9 MPa (20-130 psi) with a maximum pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C, and the recommended lubricant is ISO VG 32. It features a 25 cc drain bowl, a 36 cc oil bowl, and weighs 750 g.
The N in the model code indicates no gauge is supplied. You can install your own using the 1/8in gauge connection, but until then the exact set pressure cannot be read directly from the unit.
