Airtac GAC F.R.L. Unit GAC20006ASW
The AirTAC Airtac GAC F.R.L. Unit GAC20006ASW is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ASW
Delivering cleaned, regulated and lubricated air for single actuators, this AirTAC GAC20006ASW F.R.L. combination integrates a filter, regulator and lubricator on one L-shape bracket. The 1/8in port pairs with a 5 um element to trap fine particles before they reach precision valves. A circular gauge is fitted, reading MPa/psi for the default PT thread, so operators can monitor the 0.15-0.9 MPa (20-130 psi) standard pressure range directly.
Air passes through the filter, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat never fouls. The automatic drain clears condensate from the 25 cc bowl without an operator, a crucial feature for unattended jigs. Weighing 750 g, this compact unit is easily mounted to a panel frame rather than supported by tubing.
Airtac GAC F.R.L. Unit GAC20006ASW Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ASW |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006ASW
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ASW Is Used
Precision Micro-Valves
Feeds clean, lubricated air to sensitive micro-solenoid valves in textile machinery, where the 5 um element prevents seat contamination.
Benchtop Assembly Jigs
Conditions air for small pneumatic pick-and-place jigs on electronics assembly benches, with the automatic drain handling intermittent condensate.
Laboratory Actuators
Supplies stable pressure to single-acting cylinders in laboratory automation, using the fitted gauge to verify the 0.15-0.9 MPa operating window.
Is the Airtac GAC F.R.L. Unit GAC20006ASW the Right Air-Prep Unit?
Choose this GAC200 body for single-station duties, stepping up to the GAC300 if you need a larger 60 cc condensate bowl or a higher flow curve. The 5 um element provides finer filtration than the standard 40 um grade, ideal for sensitive instrument air, though it requires more frequent element service. If the downstream line must remain oil-free, omit the lubricator and select a separate filter-regulator instead. Spares for this body-port are GAF200-06, GAR200-06 and GAL200-06. Because the maximum supply is 1.0 MPa and the standard type regulates to 0.9 MPa, there is only about 0.1 MPa of headroom above the top setting.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ASW FAQ
This unit operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, weighs 750 g, and uses ISO VG 32 lubricant.
The 5 um element traps far finer solid particles than the standard 40 um grade, making it suitable for precision instrument air. The automatic drain clears the resulting condensate from the 25 cc bowl without manual intervention, which is decisive for unattended or wet lines.
