Airtac GAC F.R.L. Unit GAC20006ASWK
The AirTAC Airtac GAC F.R.L. Unit GAC20006ASWK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006ASWK
Delivering cleaned, regulated and lubricated air for single actuators, this GAC20006ASWK combination pre-assembles a filter, regulator and lubricator on one L-shape bracket with quick clamps. The 1/8in port feeds a 0.15-0.9 MPa (20-130 psi) standard pressure range, while the 5 um element captures fine particles for sensitive pneumatic instruments.
Because the lubricator sits last in the sequence, oil mist enters downstream of the regulator seat to prevent fouling. The automatic drain empties the 25 cc condensate bowl without an operator, and the fitted circular gauge reads MPa/psi for the default PT thread. A reverse-flow (reflux) valve is fitted, shown as a separate pneumatic symbol in the catalogue.
Airtac GAC F.R.L. Unit GAC20006ASWK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006ASWK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006ASWK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006ASWK Is Used
Miniature Pneumatic Grippers
Feeds clean, oiled air at a stable pressure to small robotic grippers handling delicate electronics assembly.
Laboratory Analytical Tools
Conditions supply air for sensitive benchtop fluid dispensers where the 5 um element protects tiny precision nozzles.
Small Spot Welding Jigs
Regulates airflow for compact pneumatic clamps on portable welding fixtures, utilizing the auto drain in humid shops.
Is the Airtac GAC F.R.L. Unit GAC20006ASWK the Right Air-Prep Unit?
This 750 g unit suits light-duty jigs rather than main plant headers, offering a 1750 L/min flow envelope at 0.7 MPa inlet. The 5 um element provides finer protection than the standard 40 um grade, extending valve life at the cost of more frequent element service. If the downstream line must remain oil-free, omit the lubricator and choose a filter-regulator instead. Spares share the 200-06 suffix: GAF200-06, GAR200-06 and GAL200-06. The 1.0 MPa maximum supply leaves only 0.1 MPa of headroom above the 0.9 MPa top setting, so plan inlet pressure carefully if you need maximum output.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006ASWK FAQ
It operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, and weighs 750 g. The recommended lubricant is ISO VG 32.
The K indicates that a reverse-flow (reflux) valve is attached. The catalogue displays this as a distinct pneumatic symbol on its own page, and no functional details are provided in our source data.
