Airtac GAC F.R.L. Unit GAC20006L
The AirTAC Airtac GAC F.R.L. Unit GAC20006L is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006L
Delivering cleaned, regulated and lubricated air for light-duty pneumatics, this assembly integrates a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port feeds the 0.15-0.4 MPa (20-58 psi) lower-pressure range, trapping particulate with a 40 um element. A circular gauge reading MPa/psi is fitted for the default PT thread, letting operators verify the setpoint directly.
Air passes through the filter, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat never fouls. The 25 cc condensate bowl and 36 cc oil capacity dictate frequent checks on this 750 g unit. If the downstream line must stay oil-free, omit the lubricator and choose a filter-regulator instead.
Airtac GAC F.R.L. Unit GAC20006L Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006L |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006L
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006L Is Used
Micro-Pneumatic Jigs
Feeds low-pressure air to delicate pick-and-place nozzles handling surface-mounted electronics.
Benchtop Tool Networks
Conditions air for miniature air motors and screwdrivers on a light assembly workstation.
Laboratory Actuators
Regulates gentle airflow for sensitive valve arrays and small clamping cylinders in test rigs.
Is the Airtac GAC F.R.L. Unit GAC20006L the Right Air-Prep Unit?
Choose this compact body for single actuators or small jigs where space is tight. The PC bowl ships with both semi-auto and manual drains, dumping condensate on pressure drops or on demand. For higher flow duties, stepping to the GAC300 increases the plotted envelope from 1750 to 3000 L/min at 0.7 MPa inlet. Spares are GAF200-06, GAR200-06 and GAL200-06. Remember that 0.4 MPa is 44% of the standard 0.9 MPa ceiling.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006L FAQ
It operates at 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and proof of 1.5 MPa (215 psi). Temperature is -5 to 70 C. It has a 25 cc drain bowl, 36 cc oil bowl, weighs 750 g, and uses ISO VG 32 lubricant.
The L indicates a lower-pressure regulator capped at 0.4 MPa. If your equipment might ever require more than 58 psi, this is the wrong part, as standard S types regulate up to 0.9 MPa.
