Airtac GAC F.R.L. Unit GAC20006LN
The AirTAC Airtac GAC F.R.L. Unit GAC20006LN is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006LN
Delivering cleaned, regulated and lubricated air for light-duty pneumatics, this AirTAC GAC20006LN combination integrates a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port pairs with a 40 um element to protect downstream actuators, while the lower-pressure type restricts the operating band to 0.15-0.4 MPa (20-58 psi). Because the lubricator sits last in the sequence, oil mist is introduced downstream of the regulator seat, preventing fouling of the internal pressure-control mechanism.
Weighing 750 g, the assembly carries a 25 cc condensate bowl and a 36 cc oil reservoir, dictating frequent maintenance checks compared to larger frames. This unit omits the pressure gauge entirely; operators must add a 1/8in gauge to the dedicated port to read the setpoint. The standard semi-auto and manual drain pair is fitted, emptying condensate on every pressure drop or on demand.
Airtac GAC F.R.L. Unit GAC20006LN Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006LN |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006LN
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006LN Is Used
Micro-Pneumatic Clamps
Feeds clean, lubricated air at low pressure to delicate clamping cylinders on electronics assembly lines.
Laboratory Air Tools
Conditions supply for benchtop air agitation or small laboratory pick-and-place arms requiring 40 um filtration.
Single-Actuator Jigs
Prepares air for individual pneumatic presses in low-force welding jigs, utilizing the 36 cc oil bowl for steady misting.
Is the Airtac GAC F.R.L. Unit GAC20006LN the Right Air-Prep Unit?
Choose this 1/8in body for single actuators or small jigs where the catalogue flow curve is plotted to 1750 L/min at 0.7 MPa inlet, which is roughly 29% of the GAC300's 3000 L/min envelope. The PC bowl suits standard -5 to 70 C environments, but buyers facing aggressive solvents should confirm material compatibility from the datasheet. If the machine requires oil-free exhaust, omit the lubricator and select a standalone filter-regulator instead. The three components are individually replaceable using GAF200-06, GAR200-06 and GAL200-06 spares. Remember that the 0.4 MPa ceiling is 44% of the standard 0.9 MPa limit, so never specify this lower-pressure variant if the equipment might later need higher force.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006LN FAQ
This lower-pressure unit regulates from 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). It operates from -5 to 70 C, weighs 750 g, holds 25 cc of condensate and 36 cc of oil, and requires ISO VG 32 lubricant.
The N in the ordering code means no gauge is supplied. The block retains a 1/8in gauge connection, so you must install a separate gauge reading in MPa/psi to verify the downstream set pressure.
