Airtac GAC F.R.L. Unit GAC20006LNW
The AirTAC Airtac GAC F.R.L. Unit GAC20006LNW is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeNot fitted
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006LNW
Delivering cleaned, regulated and lubricated air for small pneumatic duties, this AirTAC unit combines a filter, regulator and lubricator on a single L-shape bracket with quick mounting clamps. It features a 1/8in port, a 5 um element for fine particle retention, and operates at 0.15-0.4 MPa (20-58 psi). Because the set pressure cannot be read out of the box, the 1/8in gauge connection is ready for a separate instrument to be added.
Air passes through the filter first, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat never fouls. The 25 cc condensate bowl and 36 cc oil capacity mean this 750 g assembly requires frequent attention compared to larger frames. It carries a PC bowl and ships with both semi-auto and manual drains fitted.
Airtac GAC F.R.L. Unit GAC20006LNW Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006LNW |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAC200 is 1/8" if you add one.
Model Code: Airtac GAC F.R.L. Unit GAC20006LNW
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006LNW Is Used
Micro-Assembly Jigs
Feeds low-pressure air to delicate pick-and-place nozzles handling electronic components.
Laboratory Actuators
Conditions air for sensitive analytical instruments requiring 5 um filtration and stable low pressure.
Textile Guiding Cylinders
Lubricates and regulates small-bore cylinders in fine fabric tensioning systems.
Is the Airtac GAC F.R.L. Unit GAC20006LNW the Right Air-Prep Unit?
Choose this lower-pressure type for instruments or low-force actuators operating strictly under 0.4 MPa; if the machine might ever need more, select the standard type instead. The 5 um element traps far finer particles than the 40 um default, suiting precision valves but requiring more frequent element service. Since no gauge is supplied, operators must fit one to the 1/8in connection to verify the setting. If the downstream line must stay completely oil-free, omit the lubricator and choose a separate filter-regulator. Spares follow the body-port suffix exactly: GAF200-06, GAR200-06 and GAL200-06. The 0.4 MPa ceiling is 44% of the standard 0.9 MPa maximum, defining the operational limit for this unit.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006LNW FAQ
This model operates at 0.15-0.4 MPa (20-58 psi) with a maximum pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It has a 25 cc drain bowl, a 36 cc oil bowl, and weighs 750 g. The recommended lubricant is ISO VG 32.
The N in the ordering code indicates no gauge is supplied. The unit features a 1/8in gauge connection, allowing you to install a separate pressure instrument that reads in your preferred scale to monitor the 0.15-0.4 MPa range.
