Airtac GAC F.R.L. Unit GAC20006LNWK
2、The lubrication adjustment ring features single-rotation limitation (360°), with oil delivery volume demonstrating quasi-linear distribution - flow rate can be estimated through calibrated ring positioning;
3、Enables dynamic oil supply adjustment without system shutdown;
4、Specially designed drip nozzle generates negative pressure at outlet port, effectively reducing mist generation rate;
5、Quick-connect mechanism with positive locking ensures secure installation and operational convenience;
6、Pressure regulation system maintains exceptional stability with high repeatability accuracy;
7、Advanced coalescing filtration achieves superior moisture removal and particulate separation efficiency;
8、Dual drainage configurations available: differential pressure manual and automatic drainage options;
9、Cup construction materials include PC, metal, and nylon variants for diverse environmental compatibility.
Category: FRL Units (Filter-Regulator-Lubricator) | Brand: AIRTAC | Series: GAC
AirTAC GAC20006LNWK FRL Combination Unit Technical Details
- Model: GAC20006LNWK
- Type: 3-in-1 Filter-Regulator-Lubricator (FRL) unit
- Port size: PT1/4 (BSP 1/4")
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 2000 L/min (ANR)
- Filtration grade: 5 μm (with auto-drain)
- Lubricator oil capacity: 150 cm³
- Adjustable oil drip rate: 0–30 drops/min
- Body material: Anodized aluminum alloy
- Seal material: NBR/Viton optional
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Weight: 580g ±2%
- Dimensions: 152mm(L) × 68mm(W) × 146mm(H)
- Pressure gauge: 40mm dial (0-1.6 MPa scale)
- Mounting: Bracket-integrated design
Modular FRL unit combining precision air preparation functions with maintenance-friendly features. The angled filter bowl design enables space-efficient installation while maintaining 360° bowl visibility. Features a tamper-proof regulator knob and integrated bypass valve for safe pressure adjustments during operation.
- Pneumatic production line air preparation systems
- CNC machine tool pneumatic circuits
- Automated assembly equipment
- Packaging machinery lubrication control
- Robotic actuator systems
Maintenance protocol:
Replace filter element every 4,000 operational hours or when differential pressure exceeds 0.1 MPa.
Lubricator requires mineral oil ISO VG32 or equivalent. Drain bowl daily in high-humidity environments.
- Install in sequence: Filter → Regulator → Lubricator
- Maintain 50mm clearance below bowl for drainage
- Vertical mounting (±15° tolerance) required for optimal performance
- Pre-fill lubricator before initial operation
| Property | Property Value |
|---|---|
| sku | GAC20006LNWK |
| Port Size | PT1/8 |
