Airtac GAC F.R.L. Unit GAC20006LW
The AirTAC Airtac GAC F.R.L. Unit GAC20006LW is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006LW
Delivering cleaned, regulated and lubricated air for pneumatic setups, this assembly integrates a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port suits compact duties, and the 5 um element captures fine particulates before they reach sensitive valves. Air flows through the filter first, then the regulator, and finally the lubricator so oil mist is added downstream of the regulator seat.
Configured for the lower-pressure type, operation spans 0.15-0.4 MPa (20-58 psi) with a 1.0 MPa (145 psi) maximum. The PC bowl holds 25 cc of condensate and 36 cc of oil, while a circular gauge reading MPa/psi is fitted for the default PT thread. The semi-auto and manual drain pair clears accumulated moisture during routine line checks.
Airtac GAC F.R.L. Unit GAC20006LW Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006LW |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006LW
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006LW Is Used
Micro-Assembly Jigs
Feeds miniature grippers and precision nozzles in electronics assembly where low, stable pressure is critical.
Laboratory Air Tools
Conditions air for sensitive lab automation and test fixtures requiring fine 5 um filtration.
Small Benchtop Clamps
Supplies regulated, lubricated air to light-duty benchtop clamping cylinders in a workshop.
Is the Airtac GAC F.R.L. Unit GAC20006LW the Right Air-Prep Unit?
Choose this 750 g unit for single actuators or small jigs where space is tight. If the machine ever requires pressure above 0.4 MPa, the L type is the wrong part and the standard S type is needed instead. The 5 um element provides finer filtration than the 40 um standard, ideal for instrument air, though it requires more frequent element service. Because oil mist is added downstream, select a filter-regulator if the line must remain oil-free. Replacement spares share the same body and port: GAF200-06, GAR200-06 and GAL200-06. The 0.4 MPa ceiling is about 44% of the standard 0.9 MPa maximum, quantifying exactly what is sacrificed to choose this lower-pressure variant.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006LW FAQ
It operates at 0.15-0.4 MPa (20-58 psi) with a maximum pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. The drain bowl holds 25 cc and the oil bowl holds 36 cc. The unit weighs 750 g and uses ISO VG 32 lubricant.
The 5 um element traps far finer particles than the standard 40 um filter, making it suitable for precision valves or instrument air, but it will need more frequent service. The L type indicates a lower pressure range of 0.15-0.4 MPa (20-58 psi), so it cannot be used if your system requires higher operating pressures.
