Airtac GAC F.R.L. Unit GAC20006LWK
The AirTAC Airtac GAC F.R.L. Unit GAC20006LWK is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006LWK
Delivering cleaned, regulated and lubricated air for small pneumatic duties, this AirTAC GAC20006LWK combines a filter, regulator and lubricator on a single L-shape bracket. The 1/8in port feeds a 5 um element that captures fine particles, while the lower-pressure type restricts the operating band to 0.15-0.4 MPa (20-58 psi). A circular gauge is fitted, reading MPa/psi for the default PT thread.
The build sequence routes air through the filter, then the regulator, and finally the lubricator, ensuring oil mist is added downstream so the regulator seat stays clean. The 25 cc condensate bowl and 36 cc oil capacity mean this 750 g assembly requires frequent attention compared to larger frames. The reverse-flow (reflux) valve is fitted, shown as a separate pneumatic symbol in the catalogue.
Airtac GAC F.R.L. Unit GAC20006LWK Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006LWK |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006LWK
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006LWK Is Used
Micro-Assembly Jigs
Feeds delicate pick-and-place actuators handling electronic components where low, stable pressure is mandatory.
Laboratory Pneumatics
Conditions air for small-scale test fixtures requiring fine 5 um filtration and a strictly limited 0.4 MPa output.
Precision Valve Banks
Supplies clean, lubricated air to miniature solenoid valve arrays operating sensitive instrumentation circuits.
Is the Airtac GAC F.R.L. Unit GAC20006LWK the Right Air-Prep Unit?
Choose this compact 1/8in unit for single actuators or small jigs where the machine pressure is deliberately kept low. The 5 um element traps far finer particles than the standard 40 um grade, making it suitable for precision valves, though it will require more frequent element service. If the downstream line must remain completely free of oil, omit the lubricator and select a separate filter-regulator instead. The semi-auto and manual drain pair both ship fitted, emptying the 25 cc bowl on each pressure drop or on demand. Replacement spares follow the 200-06 suffix: GAF200-06, GAR200-06 and GAL200-06. Because the lower-pressure type tops out at 0.4 MPa, it operates at roughly 44% of the standard 0.9 MPa ceiling.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006LWK FAQ
This lower-pressure F.R.L. combination operates at 0.15-0.4 MPa (20-58 psi) with a maximum pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, a 5 um element, and weighs 750 g. The recommended lubricant is ISO VG 32.
The K signifies that a reverse-flow (reflux) valve is attached to this unit. The catalogue displays this component as a separate pneumatic symbol with specific details on its own page, and it is included as an ordering difference on this specific assembly.
