Airtac GAC F.R.L. Unit GAC20006S
The AirTAC Airtac GAC F.R.L. Unit GAC20006S is a genuine three-unit F.R.L. combination — a filter, a pressure regulator and a lubricator pre-assembled on one bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeCircular, MPa / psi
- Weight750 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAC F.R.L. Unit GAC20006S
Delivering cleaned, regulated and lubricated air for single actuators, the GAC20006S is a compact three-unit F.R.L. combination. It pre-assembles a 40 um filter, a pressure regulator and a lubricator on one L-shape bracket with quick mounting clamps, eliminating inter-unit tubing. This assembly feeds a 1/8in port line at a standard 0.15-0.9 MPa (20-130 psi) range, making it suitable for light-duty jigs.
The build order matters: air passes through the filter, then the regulator, and finally the lubricator. Adding oil mist downstream of the regulator prevents fluid from fouling the pressure seat. A circular gauge is fitted, reading MPa/psi for the default PT thread, so operators can monitor the set pressure directly. The unit carries a 25 cc condensate bowl and a 36 cc oil bowl, setting the maintenance frequency for this 750 g assembly.
Airtac GAC F.R.L. Unit GAC20006S Technical Specifications
| Model | Airtac GAC F.R.L. Unit GAC20006S |
|---|---|
| Series | GAC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 750 g |
Specifications follow the official AirTAC GAC catalogue (pages 216-217). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAC F.R.L. Unit GAC20006S
| GAC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAF200-06 filter, GAR200-06 regulator, GAL200-06 lubricator — all three share this body and port.
Size Class & Flow Envelope
- GAC2001/8"-1/4" · 1750 L/min
- GAC3001/4"-1/2" · 3000 L/min
- GAC4003/8"-1/2" · 6000 L/min
- GAC5003/4" · 7000 L/min
- GAC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAC300 (curve to 3000 L/min) |
| Build order | Filter → bracket → regulator → lubricator |
Where the Airtac GAC F.R.L. Unit GAC20006S Is Used
Small Pneumatic Jigs
Feeds single-actuator clamping jigs on benchtop assembly stations, providing the exact 1/8in port size and 40 um filtration needed for delicate gripping tasks.
Air-Powered Hand Tools
Conditions air for light-duty air screwdrivers and staplers, adding necessary oil mist downstream of the regulator to keep internal motor vanes lubricated.
Laboratory Automation
Regulates supply for compact pick-and-place mechanisms in lab testing rigs, where the 750 g lightweight body mounts easily to aluminum framing without stressing the structure.
Is the Airtac GAC F.R.L. Unit GAC20006S the Right Air-Prep Unit?
Choose this 1/8in port body for small pneumatic tasks rather than a larger line. The catalogue flow curve for the GAC200 is plotted to 1750 L/min at 0.7 MPa inlet, whereas the GAC300 is plotted to 3000 L/min, so step up if you are feeding multiple valves. This model uses a PC bowl, a 40 um element and a semi-auto plus manual drain pair. Spares are ordered separately as GAF200-06, GAR200-06 and GAL200-06. Note that the lubricator adds oil mist downstream, so select a filter-regulator instead if the application requires dry, oil-free air. The max supply is 1.0 MPa and the Standard type regulates to 0.9 MPa, leaving only about 0.1 MPa of headroom above the top setting.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 750 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a filter-regulator instead of an F.R.L. combination on that branch.
Airtac GAC F.R.L. Unit GAC20006S FAQ
This standard type operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and a proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C. It features a 25 cc drain bowl, a 36 cc oil bowl, a 40 um element, a recommended lubricant of ISO VG 32, and weighs 750 g.
The unit ships with both a semi-auto drain, which dumps condensate on each pressure drop, and a manual drain for on-demand emptying. A circular gauge is fitted from the factory, reading in MPa/psi to match the default PT thread, allowing direct monitoring of the regulated outlet pressure.
