Airtac GAF Filter GAF200C08A
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF200C08A Filter Specifications
- Model: GAF200C08A
- Type: Auto-drain compressed air filter
- Port size: PT1/2 (BSPP thread)
- Flow capacity: 2000 L/min (at 0.7MPa)
- Operating pressure: 0.15–1.0 MPa
- Filtration grade: 40μm (replaceable element)
- Water removal efficiency: ≥80% (at 0.7MPa)
- Max pressure loss: ≤0.02 MPa
- Operating temperature: 5℃ to 60℃
- Bowl material: Polycarbonate (metal bowl optional)
- Weight: 1.2 kg (with standard bowl)
- Dimensions: 165mm(H) × 80mm(W) × 80mm(D)
- Drain type: Semi-automatic float drain
- Seal material: NBR (compatible with oil-lubricated air)
High-capacity coalescing filter with visible bowl design, engineered for industrial compressed air systems requiring continuous operation. Features a dual-stage filtration process: first-stage centrifugal separation removes bulk liquids, followed by secondary coalescing filtration. The transparent bowl allows visual inspection of contamination levels.
- Pneumatic tool air preparation systems
- CNC machine air line protection
- Paint spray booth compressed air conditioning
- Packaging machine actuator protection
- Food processing pneumatic controls
Maintenance note:
Replace filter element when pressure drop exceeds 0.05MPa or annually.
Bowl should face away from operator access points for safety.
Install downstream of air dryer for maximum efficiency.
| Property | Property Value |
|---|---|
| sku | GAF200C08A |
| Port Size | PT1/4 |
