Airtac GAF Filter GAF200C08AJW
The AirTAC Airtac GAF Filter GAF200C08AJW is a genuine compressed-air filter. Its diversion structure spins the air to separate liquid water and trap solid particles down to 5 µm, protecting downstream valves and tools. It has 1/4" ports and a 25 cc drain bowl. It is a filter only — it does not regulate or set pressure.
- TypeAir filter
- Port size1/4"
- Filtering grade5 µm
- Pressure range0.15 - 0.9 MPa
- Bowl materialMetal
- Drainautomatic
- Drain bowl25 cc
- Weight200 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAF Filter GAF200C08AJW
The GAF200C08AJW is a genuine AirTAC air filter that spins incoming air to throw liquid water and solid particles into its 25 cc metal drain bowl, while the 5 um HDPE element traps fine grain. This 1/4in unit weighs 200 g and is built for protecting a single valve or small jig from contamination.
This filter-only model has no regulator and no pressure gauge; it cleans the air but does not control pressure. With its metal bowl and automatic drain, it suits lines where condensate builds up quickly and manual draining is inconvenient. The unit's small size means it should be mounted on a panel or frame rather than supported by the tubing.
Airtac GAF Filter GAF200C08AJW Technical Specifications
| Model | Airtac GAF Filter GAF200C08AJW |
|---|---|
| Series | GAF200 air filter |
| Port size | 1/4" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Bowl material | Metal |
| Drain type | Automatic drain |
| Bracket | Not included (J) |
| Fluid | Air |
|---|---|
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Element | HDPE filter core |
| Weight | 200 g |
Specifications follow the official AirTAC GAF catalogue (pages 225-226). Air must not freeze in the unit. This is a filter only — it separates water and solid particles but does not set or hold a downstream pressure. To regulate pressure as well, use the matching GAFR200 filter-regulator.
Model Code: Airtac GAF Filter GAF200C08AJW
| GAF200 | GA200 series air filter — sets the port range, drain-bowl capacity and weight. |
|---|---|
| C | Bowl material: Metal. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 08 | Port size 1/4". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| J | No bracket (J) — supplied without the mounting bracket. |
| W | Filtering grade 5 µm. |
| (blank) | PT port thread. |
A GAF has no regulator and no pressure gauge — there is no type, gauge or reflux code. Need to regulate pressure too? The matching GAFR200-08 is the same filter with a built-in regulator.
Size Class & Flow Envelope
- GAF2001/8"-1/4" · 3000 L/min
- GAF3001/4"-1/2" · 6000 L/min
- GAF4003/8"-1/2" · 8000 L/min
- GAF5003/4" · 9000 L/min
- GAF6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. A filter this size drops less pressure at flow than the same-body GAFR filter-regulator, so match it to your peak demand.
| This model | GAF200 · 1/4" · curve to 3000 L/min |
|---|---|
| One size up | GAF300 (curve to 6000 L/min) |
| Add regulation | GAFR200-08 (filter + regulator) |
Where the Airtac GAF Filter GAF200C08AJW Is Used
Protect a precision valve
Feed a single solenoid valve on a small indexing table. The 5 um element keeps fine wear particles from scoring the valve spool, and the automatic drain clears condensate without stopping the cycle.
Guard a portable pneumatic tool
Mount this 200 g filter ahead of an air screwdriver or nibbler on a workbench. The metal bowl survives shop knocks, and the compact body fits tight spaces near the tool inlet.
Instrument air for a test fixture
Use it to clean air for a leak tester or a small pressure transducer. The 5 um element traps fine particles that could block tiny orifices, while the automatic drain handles moisture from a humid compressor line.
Is the Airtac GAF Filter GAF200C08AJW the Right Filter?
Choose the GAF200 body for 1/8in or 1/4in ports, and step up to the GAF300 body if you need a 60 cc bowl with a 6000 L/min flow envelope. The metal bowl here is a build choice for tougher environments; confirm compatibility with your surroundings since no chemical or impact data is published. This model has the automatic drain for unattended operation, omits the bracket for panel mounting, and uses the 5 um element for finer filtration. The PT thread standard must match your fittings. If you also need a set pressure, use the matching GAFR200-08 filter-regulator instead. The 1.5 MPa proof pressure gives about a 1.67x margin over the 0.9 MPa top of the working range.
Quick checklist
- ✓ Body size for your peak flow (1/4" here)
- ✓ Element 40 µm (general) or 5 µm (fine)
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Bracket kept or removed (J)
- ✓ Need pressure control too? Use GAFR200
Installation & Maintenance Notes
- check Install with the airflow arrow: IN to OUT, bowl accessible.
- check Place the filter FIRST in the air-prep train, ahead of any regulator or lubricator.
- check Keep pressure at or below the 1.5 MPa (215 psi) proof limit.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 200 g unit on its bracket, not on the tubing.
This is a filter only — it removes water and solid particles but adds no pressure control and no lubrication. Add a GAR regulator, a GAL lubricator, or step up to the GAFR200-08 filter-regulator as your air-prep needs grow.
Airtac GAF Filter GAF200C08AJW FAQ
This AirTAC GAF200 air filter has a 1/4in port, a 5 um filtering grade, a 25 cc metal drain bowl, and weighs 200 g. The working pressure range is 0.15-0.9 MPa (20-130 psi), proof pressure is 1.5 MPa (215 psi), and temperature range is -5 to 70 C. It uses an HDPE filter core and has an automatic drain.
The automatic drain expels accumulated condensate without manual intervention, making it suitable for unattended operation or wet air lines. This model also has a metal bowl and no mounting bracket, so it is designed for panel mounting or use with an existing bracket.
