Airtac GAF Filter GAF200C08AW
2. Features minimal pressure loss, high water separation efficiency, and large bowl capacity for extended operation.
3. Selectable filtration accuracy: 5μm or 40μm options available.
4. Dual drainage configurations: manual (differential pressure) and auto-drain variants.
5. Material options include polycarbonate (PC), metal, and nylon bowls to meet diverse environmental requirements.
6. Optional fixed bracket for secure mounting solutions.
Category: Filters | Brand: AirTAC | Series: GAF
AirTAC GAF200C08AW Filter Specifications
- Model: GAF200C08AW
- Type: Miniature auto-drain compressed air filter
- Port size: PT1/8 (G1/8 optional)
- Filtration rating: 5μm (ISO 8573-1 class)
- Max flow capacity: 200 L/min (ANR)
- Operating pressure: 0.1–1.0 MPa
- Drain type: Semi-automatic float drain
- Body material: Polycarbonate (PC)
- Seal material: NBR rubber
- Temperature range: -5℃ to 60℃
- Weight: 0.23 kg
- Dimensions: 52mm(D) × 65mm(H) (excluding bracket)
- Bowl capacity: 8 cm³
- Pressure dew point reduction: 20℃ (typical)
High-efficiency coalescing filter with visible bowl design for compressed air systems. Features 360° rotatable bracket for flexible installation and integrated debris separator. The transparent bowl allows visual monitoring of contamination levels and requires 40% less space than standard filters.
- Pre-filter for pneumatic valves and cylinders
- Laboratory air supply purification
- Dental equipment air lines
- Packaging machine pneumatic circuits
- Semiconductor manufacturing tools
Maintenance tip:
Replace filter element when pressure drop exceeds 0.07MPa.
Bowl should face downward during installation (arrow mark indicates flow direction).
Drain daily in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GAF200C08AW |
| Port Size | PT1/4 |
