Airtac GAFC Air Service Unit GAFC20006AL
The AirTAC Airtac GAFC Air Service Unit GAFC20006AL is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeCircular, MPa / psi
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006AL
This GAFC20006AL is a two-piece F.R.L. combination: the filter and regulator share one body, and the lubricator is mounted beside them on a T-bracket. It filters to 40 um, regulates to 0.15-0.4 MPa (20-58 psi), and adds a metered oil mist last, so oil never passes back through the regulator seat.
The 1/8in port suits small jigs and single actuators, and the 590 g mass means it needs panel or frame support, not tubing. The automatic drain clears the 25 cc condensate bowl without an operator, while the 36 cc oil bowl sets the service interval for the ISO VG 32 lubricant it carries.
Airtac GAFC Air Service Unit GAFC20006AL Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006AL |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAFC Air Service Unit GAFC20006AL
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006AL Is Used
Bench Press Feed
Feed a small pneumatic bench press or arbor press actuator with filtered, regulated, and lubricated air at a controlled low pressure.
Portable Tool Lubrication
Protect a handheld air tool like a die grinder or impact wrench by adding a controlled oil mist to the supply line.
Lab Fixture Air
Supply a laboratory test fixture or small indexing table that needs clean, low-pressure air with consistent lubrication for sliding parts.
Is the Airtac GAFC Air Service Unit GAFC20006AL the Right Air-Prep Unit?
The L type tops out at 0.4 MPa, so if your machine may ever need more than that, step up to the standard S type instead. The automatic drain is the right call for unattended or wet lines, and the PC bowl is a build choice - confirm it suits your surroundings, since the catalogue gives no material-specific data.
Spares are orderable separately as the GAFR200-06 filter & regulator and the GAL200-06 lubricator. The circular gauge is fitted, reading MPa/psi on the PT thread. A 1.0 MPa max supply leaves about 0.6 MPa above the 0.4 MPa top of the range, so plan your inlet pressure accordingly.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006AL FAQ
This lower-pressure F.R.L. combination operates at 0.15-0.4 MPa (20-58 psi), with a max pressure of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). It has a 25 cc drain bowl and a 36 cc oil bowl, weighs 590 g, and is rated for -5 to 70 C. Use ISO VG 32 lubricant.
The A code specifies an automatic drain, which clears condensate from the 25 cc bowl without an operator. This is ideal for unattended equipment or wet supply lines where manual draining would be missed, keeping the filter element from sitting in water.
