Airtac GAFC Air Service Unit GAFC20006ALN
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC20006ALN FRL Combination Unit Specifications
- Model: GAFC20006ALN
- Type: Filter Regulator Lubricator (FRL) Combination Unit
- Port size: 1/4" BSPP (G1/4)
- Operating pressure range: 0.05–1.0 MPa
- Maximum flow rate: 1,500 L/min
- Filter micron rating: 40μm (5μm optional element available)
- Pressure gauge range: 0–1.6 MPa
- Adjustment knob torque: 0.5–0.8 N·m
- Drain type: Manual drain with anti-clogging design
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (with NBR seals)
- Weight: 1.45 kg ±3%
- Dimensions: 190mm(L) × 150mm(W) × 165mm(H)
- Mounting: Panel mount with M5 screw slots
- Protection rating: IP42 (standard configuration)
Triple-function pneumatic conditioning unit integrating 40μm filtration, precision pressure regulation (with lockable knob), and adjustable oil mist lubrication. Features dual-chamber filter bowl with debris visibility window and splash-guard lubrication mechanism. Designed for industrial environments requiring stable air quality and pressure maintenance.
- CNC machine pneumatic systems
- Automated assembly line tooling
- Plastic injection molding machines
- Packaging machinery air preparation
- Robotic actuator control systems
- Automotive paint spray systems
Installation note:
Install vertically with filter unit upstream of regulator.
Drain bowl daily in high-humidity environments.
Lubricator oil level should be maintained between MIN/MAX markers.
Allow 50mm clearance below drain port for maintenance access.
| Property | Property Value |
|---|---|
| sku | GAFC20006ALN |
| Port Size | PT1/8 |
