Airtac GAFC Air Service Unit GAFC20006ALNK
The AirTAC Airtac GAFC Air Service Unit GAFC20006ALNK is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006ALNK
This GAFC20006ALNK is a compact F.R.L. combination where the filter and regulator share one body, and a lubricator is mounted on the same T-bracket. With a 1/8" port and 590 g mass, it suits small jigs or a single actuator where space is tight.
The lower-pressure type regulates from 0.15 to 0.4 MPa (20-58 psi), and the automatic drain clears the 25 cc condensate bowl without an operator. No gauge is supplied, so the 1/8" gauge connection must be fitted if you need to read the set pressure.
Airtac GAFC Air Service Unit GAFC20006ALNK Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006ALNK |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAFC200 is 1/8" if you add one.
Model Code: Airtac GAFC Air Service Unit GAFC20006ALNK
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006ALNK Is Used
Precision fixturing
Feed a small pneumatic clamp or fixture on a benchtop assembly station where the lower pressure range protects delicate parts from over-force.
Lab air supply
Provide filtered, regulated air to a laboratory test rig or a single air bearing that requires a gentle, consistent supply below 0.4 MPa.
Maintenance tools
Power a handheld air tool or a small blow gun in a maintenance cart, where the compact size and automatic drain reduce daily checks.
Is the Airtac GAFC Air Service Unit GAFC20006ALNK the Right Air-Prep Unit?
Choose this GAFC200 if your line is 1/8" and you need the lower 0.15-0.4 MPa range. The automatic drain (A) suits unattended machines, while the PC bowl is the standard build; confirm it matches your environment. The 40 um element is the default, and the reverse-flow valve (K) is fitted as an ordering difference. The lubricator adds ISO VG 32 oil mist last, so if your line must stay oil-free, select a plain GAFR200-06 filter-regulator instead. Spares are GAFR200-06 and GAL200-06, both orderable separately. With a 1.0 MPa max supply, you have about 0.6 MPa of headroom above the 0.4 MPa top of this unit's regulated band.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006ALNK FAQ
The working pressure range is 0.15-0.4 MPa (20-58 psi), with a max pressure of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). It operates from -5 to 70 C and uses ISO VG 32 lubricant. The drain bowl holds 25 cc and the oil bowl 36 cc, with a total weight of 590 g.
The N in the code after the port means no gauge is supplied. If you need to monitor the outlet pressure, the gauge connection on the GAFC200 body is 1/8", so you can add a compatible gauge there.
