Airtac GAFC Air Service Unit GAFC20006ALNW
The AirTAC Airtac GAFC Air Service Unit GAFC20006ALNW is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006ALNW
This AirTAC GAFC20006ALNW is a two-piece F.R.L. combination: a filter and regulator share one body, and a lubricator is mounted beside them on a T-bracket. The 1/8in port size and 590 g mass suit it for small jigs, single actuators, or a compact bench station where panel space is tight.
The lower-pressure regulator is set for 0.15-0.4 MPa (20-58 psi), with a 5 um element trapping fine particles before the air reaches the lubricator. The automatic drain clears the 25 cc condensate bowl without operator attention, while the 36 cc oil bowl holds ISO VG 32 lubricant. No gauge is fitted; the 1/8in gauge connection allows adding one later.
Airtac GAFC Air Service Unit GAFC20006ALNW Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006ALNW |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAFC200 is 1/8" if you add one.
Model Code: Airtac GAFC Air Service Unit GAFC20006ALNW
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006ALNW Is Used
Precision Fixture Clamping
Feed a small pneumatic vise or indexing fixture on a benchtop assembly station, where the lower 0.4 MPa range prevents over-clamping delicate parts.
Single-Actuator Test Rig
Supply one compact air cylinder in a lab test setup, using the 5 um element to protect a precision flow-control valve from fine particulates.
Compact Panel Build
Mount on a small control panel for a semi-automatic crimping tool or a light-duty press, where the 590 g weight and 1/8in port fit tight layouts.
Is the Airtac GAFC Air Service Unit GAFC20006ALNW the Right Air-Prep Unit?
Choose the GAFC200 body for small-bore cylinders or air tools that need clean, regulated, lubricated air at modest flow. The 1/8in port and 590 g weight mean it mounts easily on a small panel or frame; the automatic drain (A) suits unattended or intermittent duty where condensate would otherwise sit in the bowl. The lower-pressure type (L) tops out at 0.4 MPa, so confirm your actuators never need more than that before selecting this model. The 5 um element (W) filters finer than the standard 40 um, at the cost of more frequent element changes. The PT thread and no-gauge option (N) leave the 1/8in gauge connection open for a field-installed gauge. Spare parts are the GAFR200-06 filter-regulator and GAL200-06 lubricator, both orderable separately. With a 1.0 MPa max supply, the regulated band leaves about 0.6 MPa of headroom above the 0.4 MPa top setting.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006ALNW FAQ
The GAFC20006ALNW operates at 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). It has a 25 cc drain bowl and a 36 cc oil bowl, weighs 590 g, and is rated for -5 to 70 C. The recommended lubricant is ISO VG 32. The 5 um element and automatic drain are fitted, and the PT thread has no gauge.
The N after the port code means no gauge is supplied with the GAFC20006ALNW. The 1/8in gauge connection is still present on the body, so you can add a circular gauge later if you need to read the set pressure directly. Until then, the regulated output is set by the adjusting knob.
