Airtac GAFC Air Service Unit GAFC20006ALNWK
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC Series FRL Combination Unit GAFC20006ALNWK Specifications
- Model: GAFC20006ALNWK
- Type: Filter Regulator Lubricator (FRL) Combination Unit
- Port size: G1/4 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Maximum pressure: 1.5 MPa
- Filtration grade: 40 μm (microns)
- Flow capacity: 2000 NL/min (ANR)
- Weight: 0.82 kg
- Dimensions: 180mm(L) × 120mm(W) × 150mm(H)
- Drain type: Manual float drain
- Pressure gauge: 1/8" dial type (0-1.6 MPa scale)
- Temperature range: 5℃ to 60℃ (non-freezing)
- Housing material: Aluminum alloy (anodized)
- Seal material: NBR (Nitrile rubber)
- Lubricator capacity: 80 cm³
- Oil viscosity range: ISO VG32-68
- Mounting style: Panel mount with bracket
- Protection rating: IP54
Compact triple-function unit integrating precision filtration (with water separator), pressure regulation, and adjustable lubrication. Features a corrosion-resistant aluminum body with ergonomic adjustment knob and visible oil level window. The dual-chamber design ensures stable pressure output with ±0.02 MPa accuracy. Optional auto-drain version available (GAFC20006ALNWKA).
- Pneumatic tool stations in automotive assembly lines
- Packaging machinery air preparation systems
- Industrial robot end-effector control systems
- Textile machinery pneumatic circuits
- Food processing equipment (NBR seals compatible)
Installation note:
Install vertically with arrow mark pointing downstream. Maintain 30cm upstream straight piping.
Drain condensate daily in high-humidity environments. Use ISO VG32 turbine oil for lubrication.
| Property | Property Value |
|---|---|
| sku | GAFC20006ALNWK |
| Port Size | PT1/8 |
