Airtac GAFC Air Service Unit GAFC20006AS
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC Series Filter Regulator Lubricator (FRL) Unit GAFC20006AS Specifications
- Model: GAFC20006AS
- Type: Compact 2-stage combination unit (Filter + Regulator)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.9 MPa
- Max flow rate: 1,800 NL/min
- Filter grade: 5 μm (40 μm optional element available)
- Pressure gauge: 1/8" dial type (0-1.0 MPa scale)
- Adjustment knob: Lockable rotary type with push-to-lock mechanism
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 0.62 kg
- Dimensions: 98mm(L) × 76mm(W) × 128mm(H)
- Drain type: Manual float-type drain cup (10ml capacity)
The GAFC20006AS combines precision air filtration and pressure regulation in a space-saving design. Features a transparent polycarbonate bowl with anti-static coating and safety shield. The integrated bypass structure maintains airflow during filter element replacement. Requires 0.1μm pre-filter for optimal performance in ISO 8573-1 Class 3 air quality systems.
- Pneumatic tool air supply stations
- CNC machine pneumatic control systems
- Automated assembly line actuators
- Packaging machinery air preparation
- Semiconductor handling equipment
Maintenance protocol:
Replace filter element every 5,000 operating hours or when pressure drop exceeds 0.1MPa.
Lubricator function requires separate installation (not included in this model).
Always depressurize system before bowl removal.
| Property | Property Value |
|---|---|
| sku | GAFC20006AS |
| Port Size | PT1/8 |
