Airtac GAFC Air Service Unit GAFC20006ASN
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC20006ASN Filter Regulator (F.R.) Unit Specifications
- Model: GAFC20006ASN
- Type: Compact 2-in-1 filter regulator
- Port size: PT1/2 (G1/2 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 3,500 L/min (ANR)
- Filtration grade: 5μm (40μm optional)
- Pressure gauge: 1/8" BSPT dial type (0-1.6 MPa range)
- Adjustment knob: Lockable rotary design
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR & polyurethane
- Temperature range: -5℃ to 60℃
- Weight: 1.25 kg
- Dimensions: 180mm(H) × 105mm(W) × 85mm(D)
- Drain type: Manual/auto drain optional
- Pressure regulation accuracy: ±0.02 MPa
Modular F.R. unit combining 5μm particulate filtration with precision pressure regulation. Features a tamper-proof adjustment knob with pressure lock mechanism and corrosion-resistant construction. The dual-chamber design minimizes pressure drop (ΔP ≤0.03 MPa at max flow). Includes integrated mounting slots for rail or panel installation.
- Centralized pneumatic control systems
- Plastic injection molding machines
- Automated assembly line tooling
- Food processing pneumatic circuits
- Semiconductor manufacturing equipment
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain 200mm clearance below drain port for maintenance access.
Pre-charge system to 0.3MPa before fine adjustment.
| Property | Property Value |
|---|---|
| sku | GAFC20006ASN |
| Port Size | PT1/8 |
