Airtac GAFC Air Service Unit GAFC20006ASNW
The AirTAC Airtac GAFC Air Service Unit GAFC20006ASNW is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeNot fitted
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006ASNW
This GAFC20006ASNW is a compact F.R.L. combination built as two pieces on one T-bracket: a filter-regulator body handles filtration and pressure setting, then a lubricator adds a metered oil mist downstream. With a 1/8in port and 590 g mass, it suits small jigs and single actuators where space is tight and the tubing should not carry the unit's weight.
The standard pressure range is 0.15-0.9 MPa (20-130 psi), and the 5 um element traps finer particles than the standard 40 um grade. The automatic drain clears condensate from the 25 cc bowl without operator attention, while the 36 cc oil bowl holds enough ISO VG 32 for extended runs between refills.
Airtac GAFC Air Service Unit GAFC20006ASNW Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006ASNW |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAFC200 is 1/8" if you add one.
Model Code: Airtac GAFC Air Service Unit GAFC20006ASNW
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006ASNW Is Used
Precision fixturing
Feed a small pneumatic clamp on a CNC fixture with clean, regulated air at a consistent 0.5 MPa setpoint, while the 5 um element protects the clamp's pilot valve from fine wear particles.
Bench assembly tools
Supply a handheld screwdriver or riveting tool on a workbench where the 590 g unit mounts directly to a light frame, and the automatic drain handles condensate from humid shop air without daily checks.
Lab air logic
Run a small air cylinder in a test rig that needs oil-misted actuation but clean, regulated pressure. The 5 um element keeps the logic valve reliable, and the 36 cc oil bowl supports long test cycles.
Is the Airtac GAFC Air Service Unit GAFC20006ASNW the Right Air-Prep Unit?
Choose this GAFC200 when your air consumption fits a 1/8in port and the 1750 L/min plotted flow envelope at 0.7 MPa inlet covers the duty. The PC bowl is the standard build; confirm it suits your environment since the catalogue lists no material-specific ratings. The automatic drain (A code) removes the need for manual draining, and the 5 um element (W) protects precision valves but needs more frequent service than 40 um.
The no-gauge version leaves the 1/8in gauge connection open for a later add-on. Spares are the GAFR200-06 filter-regulator and GAL200-06 lubricator, both orderable separately. With a 1.0 MPa max supply, you have about 0.1 MPa above the 0.9 MPa top of the regulated range, so plan the inlet pressure carefully if you need the full output.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006ASNW FAQ
This F.R.L. combination operates at 0.15-0.9 MPa (20-130 psi) with a max pressure of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). The temperature range is -5 to 70 C, and it uses ISO VG 32 lubricant. It has a 25 cc drain bowl and a 36 cc oil bowl, weighs 590 g, and uses a 5 um element.
The N after the port code means no gauge is supplied with this unit. The gauge connection on the GAFC200 body is 1/8in, so you can add a compatible pressure gauge later if you need to read the set pressure directly. Until then, the regulated output cannot be verified visually on the unit itself.
