Airtac GAFC Air Service Unit GAFC20006ASNWK
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC20006ASNWK FRL Combination Unit Specifications
- Model: GAFC20006ASNWK
- Type: Filter-Regulator (FR) Combination with Auto Drain
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 2,500 L/min (ANR)
- Filtration grade: 5 μm (with 0.3μm optional coalescing filter)
- Pressure gauge: Built-in 1/8" dial gauge (0-1.6 MPa range)
- Body material: Anodized aluminum alloy
- Seal material: NBR/Hydrogenated NBR
- Temperature range: -20℃ to 80℃ (non-freezing)
- Weight: 0.68 kg
- Dimensions: 152mm(L) × 98mm(W) × 128mm(H)
- Drain type: Semi-automatic float drain
- Pressure adjustment: Lockable rotary knob (±2% accuracy)
- Protection rating: IP42 (IP65 with optional cover)
Professional-grade air preparation unit combining precision filtration and pressure stabilization. Features a dual-chamber design with visible bowl contamination indicator (360° rotatable). The corrosion-resistant construction includes a metal bowl protector and anti-backspin filter element. Compatible with ISO 8573-1 air quality standards.
- CNC machine pneumatic systems
- Industrial robot end-effector controls
- Packaging line air tool regulation
- Semiconductor manufacturing equipment
- Food-grade pneumatic systems (with optional stainless steel bowl)
Installation note:
Install vertically with arrow marking aligned to airflow direction.
Maintain minimum 50mm clearance below drain port. Perform weekly
bowl inspection in high-humidity environments. Use torque ≤15N·m
during port connection.
| Property | Property Value |
|---|---|
| sku | GAFC20006ASNWK |
| Port Size | PT1/8 |
