Airtac GAFC Air Service Unit GAFC20006ASW
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC20006ASW Filter Regulator Lubricator (FRL) Unit Specifications
- Model: GAFC20006ASW
- Type: 2-stage combination unit (Filter + Regulator)
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.15–1.0 MPa
- Maximum flow rate: 3,000 L/min
- Filter rating: 5 μm (40 μm optional element available)
- Pressure gauge range: 0.1–1.0 MPa (dual scale: MPa & psi)
- Adjustment knob rotation: 270° with lockable design
- Housing material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.5 kg (with bracket)
- Dimensions: 180mm(L) × 150mm(W) × 180mm(H)
- Drain type: Manual push-button with splash guard
- Mounting: Panel or bracket installation
Modular FRL unit combining 5μm filtration and precision pressure regulation, featuring a tamper-proof adjustment knob with full-range locking capability. The transparent bowl allows visual contamination monitoring, while the ergonomic drain design enables single-hand operation. Compatible with ISO 8573-1 air quality standards.
- Pneumatic production line air preparation
- CNC machine tool pneumatic systems
- Packaging machinery pressure stabilization
- Automotive assembly line tool air supply
- Semiconductor manufacturing clean air systems
Maintenance protocol:
Replace filter element every 2,000 operational hours or when pressure drop exceeds 0.1 MPa.
Always depressurize system before bowl removal. For vertical installation, maintain minimum
50mm clearance below drain port for maintenance access.
| Property | Property Value |
|---|---|
| sku | GAFC20006ASW |
| Port Size | PT1/8 |
