Airtac GAFC Air Service Unit GAFC20006ASWK
The AirTAC Airtac GAFC Air Service Unit GAFC20006ASWK is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainautomatic
- Pressure gaugeCircular, MPa / psi
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006ASWK
This GAFC20006ASWK is a compact F.R.L. combination built as two joined units: a filter-regulator body handling filtration and pressure setting, paired with a lubricator that meters oil mist into the air stream last. The 1/8in port size and 590 g mass suit small jigs, single actuators, or bench-mounted tooling where space is tight and the air demand is modest.
The standard pressure range is 0.15-0.9 MPa (20-130 psi), and the 5 um element traps finer particles than the standard 40 um grade, protecting sensitive valves and instruments downstream. A circular gauge is fitted with an MPa/psi scale for the PT thread, and the automatic drain clears condensate from the 25 cc bowl without operator attention. The separate 36 cc oil bowl feeds the lubricator with ISO VG 32 oil.
Airtac GAFC Air Service Unit GAFC20006ASWK Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006ASWK |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Automatic drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAFC Air Service Unit GAFC20006ASWK
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| A | Drain: Automatic drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006ASWK Is Used
Precision Valve Control
Feed a small pilot-operated valve or a precision regulator station on a lab bench, where the 5 um element protects fine internal passages from particle wear.
Bench Tooling
Supply a pneumatic press or a riveting fixture on a workbench, where the compact 590 g body mounts directly to a frame without needing heavy support.
Single Actuator Line
Run a short line to one air cylinder on a packaging machine, with the automatic drain handling condensate in a location that operators rarely check.
Is the Airtac GAFC Air Service Unit GAFC20006ASWK the Right Air-Prep Unit?
Choose this GAFC200 when your line is 1/8in and the flow demand sits within the catalogue's plotted envelope of 1750 L/min at 0.7 MPa inlet. The 5 um element suits precision pneumatic controls, though it will need more frequent service than a 40 um grade. The automatic drain is the right call for unattended equipment or wet supply lines, and the reverse-flow valve is fitted per the K code. The PC bowl is the standard build; confirm it suits your environment, as the catalogue gives no material-specific ratings.
Spare parts are the GAFR200-06 filter-regulator and GAL200-06 lubricator, both orderable separately. If your process requires oil-free air downstream, omit the lubricator and select a plain GAFR filter-regulator instead. The max supply of 1.0 MPa leaves about 0.1 MPa above the 0.9 MPa top of the regulated range, so plan inlet pressure carefully if you need the full output.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006ASWK FAQ
The working pressure range is 0.15-0.9 MPa (20-130 psi), with a max pressure of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). Operating temperature is -5 to 70 C. The drain bowl holds 25 cc and the oil bowl 36 cc. Recommended lubricant is ISO VG 32, and the complete unit weighs 590 g.
The K code specifies that a reverse-flow (reflux) valve is fitted to this GAFC20006ASWK. The catalogue represents it as a separate pneumatic symbol in the circuit diagram. It is an ordering difference to note when comparing models; the valve is included as part of this build.
