Airtac GAFC Air Service Unit GAFC20006LN
The AirTAC Airtac GAFC Air Service Unit GAFC20006LN is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.4 MPa (20 - 58 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.4 MPa (20 - 58 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeNot fitted
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006LN
This AirTAC GAFC20006LN is a two-piece F.R.L. combination built around a 1/8in port. The filter and regulator share one body, so the set is a filter-regulator paired with a lubricator on a single T bracket. It handles lower-pressure duties in the 0.15-0.4 MPa (20-58 psi) band with a 40 um element.
The 25 cc condensate bowl and 36 cc oil bowl set the service rhythm for this 590 g unit. Air is filtered and regulated first, then the lubricator adds a metered oil mist downstream, so oil never travels back through the regulator seat. No gauge is supplied, but the 1/8in gauge connection is there if you add one later.
Airtac GAFC Air Service Unit GAFC20006LN Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006LN |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.4 MPa (20 - 58 psi) |
| Type | Lower pressure |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAFC200 is 1/8" if you add one.
Model Code: Airtac GAFC Air Service Unit GAFC20006LN
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| L | Lower pressure type — 0.15 - 0.4 MPa (20 - 58 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006LN Is Used
Bench Assembly Jigs
Feed a single pneumatic press or clamping jig on a workbench where the 1/8in port matches small-bore actuators and the lower pressure range protects delicate parts.
Lab Air Circuits
Supply instrument air to a lab fixture that needs regulated pressure below 0.4 MPa, with the lubricator adding oil for a small pneumatic valve or cylinder.
Light Duty Indexing
Run a light indexing table or parts feeder where the 590 g weight suits panel mounting and the 25 cc bowl handles modest condensate loads between shifts.
Is the Airtac GAFC Air Service Unit GAFC20006LN the Right Air-Prep Unit?
Choose this GAFC20006LN when your circuit runs below 0.4 MPa and you need the compact 1/8in port size. The L type tops out at 0.4 MPa, so if the machine may ever need more pressure, pick the standard S type instead. The PC bowl is the default build, and the semi-auto drain dumps on each pressure drop while the manual drain works on demand. The 5 um element option is available if you need finer filtration than the standard 40 um. Spare parts are orderable as GAFR200-06 and GAL200-06. The 1.0 MPa max supply leaves about 0.6 MPa above the 0.4 MPa top of the range, so plan the inlet pressure accordingly.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006LN FAQ
The GAFC20006LN operates at 0.15-0.4 MPa (20-58 psi) with a max pressure of 1.0 MPa (145 psi) and proof pressure of 1.5 MPa (215 psi). Temperature range is -5 to 70 C. It has a 25 cc drain bowl and 36 cc oil bowl, weighs 590 g, and uses ISO VG 32 lubricant. The element is 40 um and the port is 1/8in.
The N after the port code means no gauge is supplied with this unit. The gauge connection is 1/8in if you want to add one later. Without a gauge, you cannot read the set pressure directly on the unit, so plan to install one if the application requires monitoring.
