Airtac GAFC Air Service Unit GAFC20006LNK
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC Series Filter Regulator Lubricator (FRL) Unit GAFC20006LNK Specifications
- Model: GAFC20006LNK
- Type: Compact 2-stage combination unit (Filter + Regulator)
- Port size: 1/4" BSPP (G1/4)
- Operating pressure range: 0.05-0.85 MPa
- Maximum flow rate: 3,500 L/min (ANR)
- Filter element: 5μm sintered bronze (replaceable)
- Pressure gauge: 1/8" dial type (MPa scale)
- Adjustment knob: Lockable rotary type with safety release
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 60℃
- Weight: 820g ±5%
- Dimensions: 150mm(L) × 80mm(W) × 110mm(H)
- Drain type: Manual push-button with splash guard
- Mounting: Panel mount with M5 threaded holes
Integrated pneumatic conditioning unit combining 5μm filtration and precision pressure regulation. Features a tamper-proof adjustment knob with full-range lock mechanism and visible pressure indication. The bowl guard design meets ISO 4414 safety standards, with automatic pressure relief when opening the filter bowl.
- CNC machine tool pneumatic systems
- Automated assembly line air preparation
- Packaging machinery main air supply
- Industrial robot end-effector control
- Plastic injection molding machines
Installation guidelines:
Install vertically with arrow mark pointing downstream. Maintain minimum 300mm straight pipe
upstream. Drain daily in high-humidity environments. Replace filter element every 2,000 operational
hours or when pressure drop exceeds 0.05MPa.
- Optional lubricator module: GALC20006
- Pressure gauge alternatives: 0-1.6MPa or PSI scales
- Bowl protection cover: GCP-25A (anti-impact)
| Property | Property Value |
|---|---|
| sku | GAFC20006LNK |
| Port Size | PT1/8 |
