Airtac GAFC Air Service Unit GAFC20006LNWK
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC20006LNWK Filter Regulator Unit Technical Details
- Full model code: GAFC20006LNWK
- Configuration: Combination unit (Filter + Regulator)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–0.9 MPa
- Max flow capacity: 2,200 NL/min
- Filtration grade: 5μm (40μm pre-filter mesh)
- Pressure gauge interface: Rc1/8
- Adjustment knob rotation: 270° with lockable dial
- Weight: 0.82 kg (1.81 lbs)
- Dimensions: 198mm(L) × 65mm(W) × 115mm(H)
- Body material: Anodized aluminum alloy
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Drain type: Manual drain with anti-splash shield
- Pressure relief: Built-in safety valve at 1.1 MPa
Modular air preparation unit combining particulate filtration and precision pressure regulation. Features dual-chamber construction with visible bowl design for maintenance monitoring. The corrosion-resistant bowl withstands 1.5MPa burst pressure and includes a sediment baffle for improved separation efficiency.
- Pneumatic tool air supply stations
- CNC machine pneumatic control lines
- Automated assembly line pressure stabilization
- Packaging machinery air circuit protection
- Robotic actuator pressure management systems
Maintenance protocol:
Replace filter element every 3,000 operational hours or when pressure drop exceeds 0.1MPa.
Bowl tightening torque should not exceed 3.5N·m during servicing.
- Kv value: 3.2
- Cv value: 3.7
- Pressure regulation accuracy: ±0.008 MPa
- Hysteresis: ≤1.5% F.S.
| Property | Property Value |
|---|---|
| sku | GAFC20006LNWK |
| Port Size | PT1/8 |
