Airtac GAFC Air Service Unit GAFC20006S
The AirTAC Airtac GAFC Air Service Unit GAFC20006S is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 40 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade40 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeCircular, MPa / psi
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006S
This GAFC20006S is a compact F.R.L. combination where the filter and regulator share one body, paired with a lubricator on a single bracket. With a 1/8in port and 590 g mass, it suits small jigs or single actuators where space is tight. The 40 um element handles standard shop air, and the circular gauge reads in MPa/psi.
Air enters the first body, gets filtered and set to 0.15-0.9 MPa (20-130 psi), then the lubricator adds a metered oil mist downstream. The 25 cc condensate bowl and 36 cc oil bowl set the service rhythm for light duty. Both semi-auto and manual drains are fitted, so condensate can be dumped automatically on pressure drop or on demand.
Airtac GAFC Air Service Unit GAFC20006S Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006S |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 40 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. The fitted circular gauge reads in MPa / psi, set by the PT thread code.
Model Code: Airtac GAFC Air Service Unit GAFC20006S
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| (blank) | Circular pressure gauge fitted. |
| (blank) | Filtering grade 40 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| (blank) | No reverse-flow valve. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006S Is Used
Bench Press Feed
Feed a small pneumatic bench press or arbor press actuator with filtered, regulated, lubricated air at a consistent 0.6 MPa setpoint.
Air Tool Station
Supply a single air screwdriver or die grinder on a maintenance cart, with the lubricator keeping the tool's internal vanes oiled.
Lab Fixture Cylinder
Operate a small clamping cylinder on a test fixture, where the 40 um filter protects the valve and the regulator holds a stable low pressure.
Is the Airtac GAFC Air Service Unit GAFC20006S the Right Air-Prep Unit?
Choose this GAFC200 body for 1/8in porting and light flow needs. The PC bowl is the standard build; the catalogue lists no material-specific ratings, so confirm it suits your environment. The semi-auto plus manual drain pair handles intermittent use well. The 40 um element is the default; step to the 5 um W option for finer filtration. The PT thread carries an MPa/psi gauge scale. For oil-free lines, skip the lubricator and select a plain GAFR200-06 filter-regulator instead. Spares for this model are GAFR200-06 and GAL200-06. With a 1.0 MPa max supply, you have about 0.1 MPa of headroom above the 0.9 MPa top of the regulated range, so plan the inlet pressure accordingly.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006S FAQ
The working pressure range is 0.15-0.9 MPa (20-130 psi). Maximum pressure is 1.0 MPa (145 psi) and proof pressure is 1.5 MPa (215 psi). It operates from -5 to 70 C and must not freeze. The drain bowl holds 25 cc and the oil bowl 36 cc. Recommended lubricant is ISO VG 32. The unit weighs 590 g.
The GAFC20006S includes both a semi-auto drain and a manual drain. The semi-auto drain automatically expels condensate each time the air pressure drops, such as when the system is shut down. The manual drain provides a simple push-button or twist-valve option for on-demand dumping without waiting for a pressure cycle.
