Airtac GAFC Air Service Unit GAFC20006SK
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC Series Twin Unit GAFC20006SK Technical Details
- Model: GAFC20006SK (Filter Regulator Combination)
- Port size: 1/4" BSPP (G1/4)
- Operating pressure range: 0.05-1.0 MPa
- Maximum pressure: 1.5 MPa
- Filtration grade: 5 μm (with auto-drain)
- Pressure gauge: 1/8" NPT dial (0-1.6 MPa scale)
- Flow capacity: 3,500 Nl/min (at 0.7 MPa)
- Adjustment knob: Lockable rotary type with ±2% accuracy
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 70℃ (non-freezing)
- Weight: 1.25 kg ±5% (dry condition)
- Dimensions: 198mm(H) × 96mm(W) × 143mm(D)
- Mounting: Panel bracket optional (ISO 4414 compliant)
Professional-grade air preparation unit combining precision filtration and pressure stabilization. Features a transparent bowl with safety shield and anti-rotation lock nut design. The integrated bypass valve maintains system pressure during element replacement. Requires 10-15% less maintenance than standard units due to cyclone separation technology.
- CNC machine pneumatic control systems
- Plastic injection molding air lines
- Automated assembly line tooling
- Food packaging machinery (FDA-compliant version available)
- Semiconductor manufacturing equipment
Maintenance protocol:
Replace filter element every 4,000 operational hours or when pressure drop exceeds 0.1 MPa.
Lubricator (if equipped) requires weekly oil level checks using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | GAFC20006SK |
| Port Size | PT1/8 |
