Airtac GAFC Air Service Unit GAFC20006SNW
2、Stable pressure regulation with high repeatability accuracy;
3、High-efficiency moisture and solid particle elimination capability:
4、Dual drainage options: differential pressure manual drainage or automatic drainage;
5、Multiple bowl material selections including polycarbonate (PC), metal, and nylon to adapt to diverse operational environments.
Category: F.R.L. Combination Units , Brand: AirTAC , Series: GAFC
AirTAC GAFC20006SNW Filter-Regulator Combination Unit Specifications
- Model: GAFC20006SNW
- Type: Filter-Regulator (F.R.L) Combination Unit
- Port size: PT3/8 (G3/8 optional)
- Operating pressure range: 0.05–0.9 MPa
- Maximum flow: 2,200 L/min
- Filtration grade: 5μm (40μm pre-filter mesh)
- Pressure gauge: Built-in 1/8" dial (0-1.6 MPa scale)
- Drain type: Semi-automatic plunger
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR/FKM hybrid
- Temperature range: -5℃ to 60℃ (non-freezing)
- Weight: 1.25 kg ±5%
- Dimensions: 160mm(H) × 90mm(W) × 105mm(D)
- Mounting: Panel bracket or rail mountable
Industrial-grade air preparation unit combining precision filtration and pressure regulation. Features dual-chamber design with visible bowl contamination indicator. The integrated bypass valve maintains airflow during filter replacement. Rated for ISO 8573-1:2010 Class 4 compressed air standards.
- Pneumatic tool stations in automotive assembly lines
- Packaging machinery air line conditioning
- CNC machine tool pneumatic systems
- Industrial robotics end-effector control
- Semiconductor manufacturing clean air supply
Installation protocol:
Install downstream of main air supply with minimum 300mm straight piping before unit.
Drain bowl requires weekly manual purge in high-humidity environments.
For vertical mounting, ensure pressure gauge orientation faces operator access side.
| Property | Property Value |
|---|---|
| sku | GAFC20006SNW |
| Port Size | PT1/8 |
