Airtac GAFC Air Service Unit GAFC20006SNWK
The AirTAC Airtac GAFC Air Service Unit GAFC20006SNWK is a genuine two-piece F.R.L. combination — a GA-series filter & regulator and a lubricator pre-assembled on one T-shape bracket with quick mounting clamps. It has 1/8" ports, a 5 µm filter element and regulates 0.15 - 0.9 MPa (20 - 130 psi).
- TypeF.R.L. combination
- Port size1/8"
- Pressure range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- Bowl materialPC
- Drainsemi-auto + manual
- Pressure gaugeNot fitted
- Weight590 g
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac GAFC Air Service Unit GAFC20006SNWK
This AirTAC GAFC20006SNWK is a compact F.R.L. combination built as two units on one T-shape bracket: the filter and regulator share a single body, and the lubricator sits downstream. It handles a 1/8in port and delivers air cleaned to 5 um, regulated from 0.15 to 0.9 MPa (20-130 psi), then oil-misted for downstream components.
The 25 cc condensate bowl and 36 cc oil bowl set the service rhythm for this 590 g unit, and the semi-auto drain dumps water each time pressure drops. With no gauge fitted, the 1/8in gauge connection is available if you add one later. A reverse-flow valve is included on this model.
Airtac GAFC Air Service Unit GAFC20006SNWK Technical Specifications
| Model | Airtac GAFC Air Service Unit GAFC20006SNWK |
|---|---|
| Series | GAFC200 F.R.L. combination |
| Port size | 1/8" (PT thread) |
| Filtering grade | 5 µm |
| Pressure range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Type | Standard |
| Bowl material | PC |
| Drain type | Semi-auto drain + manual drain |
| Fluid | Air |
|---|---|
| Max. pressure | 1.0 MPa (145 psi) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Capacity of drain bowl | 25 cc |
| Capacity of oil bowl | 36 cc |
| Recommended lubricant | ISO VG 32 or equivalent |
| Weight | 590 g |
Specifications follow the official AirTAC GAFC catalogue (pages 219-220). Air must not freeze in the unit. No gauge is supplied with this model — the gauge connection on a GAFC200 is 1/8" if you add one.
Model Code: Airtac GAFC Air Service Unit GAFC20006SNWK
| GAFC200 | GA200 series F.R.L. unit — sets ports, bowl capacity and weight. |
|---|---|
| (blank) | Bowl material: PC. Available on this body: PC (blank), Metal (C), Nylon (N). |
| 06 | Port size 1/8". This body offers 06 = 1/8", 08 = 1/4". |
| (blank) | Drain: Semi-auto drain + manual drain. |
| S | Standard type — 0.15 - 0.9 MPa (20 - 130 psi). This body offers Standard (S) or Lower pressure (L). |
| N | No pressure gauge; 1/8" gauge connection. |
| W | Filtering grade 5 µm. |
| (blank) | PT thread; gauge scale MPa / psi. |
| K | Reverse-flow (reflux) valve attached. |
Constituent units, orderable separately as spares: GAFR200-06 filter & regulator, GAL200-06 lubricator — both share this body and port. A GAFC has two units, not three: the filter and the regulator are one body.
Size Class & Flow Envelope
- GAFC2001/8"-1/4" · 1750 L/min
- GAFC3001/4"-1/2" · 3500 L/min
- GAFC4003/8"-1/2" · 6000 L/min
- GAFC5003/4" · 7000 L/min
- GAFC6003/4"-1" · 12000 L/min
Figures are the end of the flow curve plotted in the AirTAC catalogue at 0.7 MPa inlet pressure — a sizing envelope for comparing bodies, not a rated flow. Read the catalogue curve for a real duty point. Outlet pressure falls as flow rises, so size a body with headroom above your peak demand.
| This model | GAFC200 · 1/8" · curve to 1750 L/min |
|---|---|
| One size up | GAFC300 (curve to 3500 L/min) |
| Build order | Filter & regulator → bracket → lubricator |
Where the Airtac GAFC Air Service Unit GAFC20006SNWK Is Used
Precision Fixture Clamping
Feed a small pneumatic clamp on a benchtop assembly fixture with 5 um filtered air, keeping the actuation consistent and protecting the valve from fine particulates.
Single-Actuator Lubrication
Supply a single air cylinder on a packaging line with a metered oil mist, ensuring the seal and rod stay lubricated through repeated cycles.
Lab Air Preparation
Prepare instrument air for a small lab setup that needs regulated pressure and fine filtration, while the lubricator protects downstream pneumatic components.
Is the Airtac GAFC Air Service Unit GAFC20006SNWK the Right Air-Prep Unit?
Choose the GAFC200 when a single actuator or small jig needs filtered, regulated, lubricated air without taking up much panel space. The 5 um element traps finer particles than the standard 40 um grade, which suits precision valves but means more frequent element checks. The PC bowl is the default build; confirm it fits your environment, since the catalogue gives no material-specific ratings. The semi-auto drain plus manual drain covers both automatic dumping on pressure drop and on-demand draining. Since the lubricator adds oil mist, select a plain GAFR filter-regulator instead if your line must stay oil-free. Spare units are orderable as GAFR200-06 and GAL200-06. With a 1.0 MPa max supply, you have about 0.1 MPa above the 0.9 MPa top of the regulated range, so plan inlet pressure near 1.0 MPa if you need the full output.
Quick checklist
- ✓ Body size for your peak flow (1/8" here)
- ✓ Standard 0.9 MPa or lower-pressure 0.4 MPa
- ✓ Bowl material: PC (blank), Metal (C), Nylon (N)
- ✓ Drain: semi-auto + manual, or automatic
- ✓ Element 40 µm or 5 µm
- ✓ Thread & gauge scale (PT / G / NPT)
Installation & Maintenance Notes
- check Install with the airflow arrow: filter-regulator first, lubricator last.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Fill the oil bowl with ISO VG 32 or equivalent only.
- check Drain condensate before the 25 cc bowl fills.
- check Keep the unit above freezing (-5 to +70 °C, unfreeze).
- check Support the 590 g unit on its bracket, not on the tubing.
The lubricator adds an oil mist downstream of the regulator. If any part of the line must stay oil-free, use a plain GAFR200-06 filter-regulator on that branch instead of the full combination.
Airtac GAFC Air Service Unit GAFC20006SNWK FAQ
This F.R.L. combination operates from 0.15 to 0.9 MPa (20-130 psi) with a 1.0 MPa (145 psi) maximum and 1.5 MPa (215 psi) proof pressure. It works in -5 to 70 C temperatures and uses ISO VG 32 oil. The drain bowl holds 25 cc, the oil bowl 36 cc, and the unit weighs 590 g.
The N in the code after the port means no gauge is supplied. The GAFC200 body has a 1/8in gauge connection, so you can add a compatible gauge later if you need to read the set pressure directly.
