AirTAC GFC200-06 Combination Unit (GFC20006C1WK)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006C1WK) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 5 µm element, a differential-pressure drain and regulation over 0.15 - 0.9 MPa (20 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006C1WK)
The GFC20006C1WK is an AirTAC G-series two-unit set: a filter regulator plus a separate lubricator, providing filtration, pressure regulation and oil-mist lubrication in one purchase. This configuration is the compact 200 size with 1/8 in PT ports, a differential-pressure drain on the filter bowl, the fine 5 um filter element (W), a round external pressure gauge on the MPa scale, and a reverse (check) valve fitted (K). The 200-size bowls are polycarbonate (PC).
This is a genuine AirTAC part. The GFC family is offered in 200/300/400/600 sizes with 1/8 in to 1 in ports, manual, automatic or differential-pressure drains, 40 um or 5 um elements, gauge and thread options. Maximum working pressure is 1.0 MPa (145 psi) and with this differential-pressure drain the regulator adjusts from 0.15 to 0.9 MPa (20-130 psi). Flow figures are published as curves, so we confirm datasheet and sizing figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006C1WK) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006C1WK) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — round, MPa scale |
| Reflux valve | Fitted (reverse flow permitted) |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006C1WK)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| C | Gauge shape: Round. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| K | Reverse-flow (reflux) valve fitted. |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006C1WK) Is Used
Pilot-air supply to process valves
Mounted on the pilot-air line of a process valve manifold, the 5 um element protects pilot spools while the check valve guards against back-flow on supply dips.
Wire and cable cutting station
Fitted at the air feed of a cable cutting and crimping station, it filters to 5 um, holds set pressure with the check valve, and oils the cutter cylinder.
Air jet on a small printing unit
Installed ahead of the air-jet nozzles on a small print head cleaning unit, it delivers clean, regulated, lightly oiled air to the jet circuit.
Is the AirTAC GFC200-06 Combination Unit (GFC20006C1WK) the Right Set?
This code bundles the two most common upgrades on the 200-size set: the 5 um element (W) for finer filtration than the 40 um standard, and the check valve (K) to help hold downstream pressure when the supply dips. Ports are 1/8 in PT; order G or NPT if your piping needs them. Drain is differential-pressure for automatic condensate bleeding; manual (M) suits dry, intermittent circuits. Gauge is the round external type on MPa scale.
Flow is published as curves, not a single rating, so ask us to confirm sizing against your application before ordering.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006C1WK) FAQ
Flow for the AirTAC G series is published as characteristic curves rather than a single rated figure, so no rated number appears on this page. Contact us with your air demand and we will confirm the datasheet curve for the 200 size before you order.
W sets the filter element to 5 um instead of the 40 um standard, for finer protection of downstream components. K fits a reverse (check) valve in the regulator to help hold downstream pressure if the supply drops. Both are optional codes; the base set without them filters, regulates and lubricates identically.
