AirTAC GFC200-06 Combination Unit (GFC20006F1W)
The AirTAC AirTAC GFC200-06 Combination Unit (GFC20006F1W) is a genuine G-series two-unit air-preparation set: a filter regulator that filters and regulates in one body, coupled to a lubricator. Two bodies do the work of three, with PT1/8" ports, a 5 µm element, a differential-pressure drain and regulation over 0.15 - 0.9 MPa (20 - 130 psi).
- TypeTwo-unit set (F.R. + L.)
- Port sizePT1/8"
- Regulating range0.15 - 0.9 MPa (20 - 130 psi)
- Filtering grade5 µm
- DrainDifferential-pressure drain
- Bowl materialPC
- Pressure gaugeFitted
- ThreadPT
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the AirTAC GFC200-06 Combination Unit (GFC20006F1W)
GFC20006F1W is an AirTAC G-series two-unit air preparation set: a filter regulator plus a lubricator supplied as a matched pair, covering water and particle removal, pressure regulation and oil-mist lubrication in a single order. This configuration is size 200 with a 1/8 in PT port. The W code selects the finer 5 um filter element instead of the standard 40 um, the bowl is differential-pressure drained (the standard arrangement), the regulator is the standard type covering 0.15-0.9 MPa (20-130 psi), and the embedded square gauge reads in MPa. Both bowls are polycarbonate at size 200.
This is a genuine AirTAC part for compressed air only, rated to 1.0 MPa (145 psi) maximum working pressure and -5 to 70 C (non-freezing). The G-series runs from size 200 to 600 with ports from 1/8 to 1 in; related options include automatic or manual drain, other gauge scales or an external round gauge, G (BSPP) and NPT threads, and bracket choice. G-series flow is published as curves rather than a single rated figure, so we confirm datasheet and sizing figures on request.
AirTAC GFC200-06 Combination Unit (GFC20006F1W) Technical Specifications
| Model | AirTAC GFC200-06 Combination Unit (GFC20006F1W) |
|---|---|
| Series | GFC200 two-unit set |
| Composition | Filter regulator + lubricator (2 units) |
| Port size | PT1/8" (PT thread) |
| Filtering grade | 5 µm |
| Regulating range | 0.15 - 0.9 MPa (20 - 130 psi) |
| Pressure type | Standard type |
| Fluid | Compressed air |
|---|---|
| Max. working pressure | 1.0 MPa (145 psi) |
| Temperature range | -5 to +70 °C (unfreeze) |
| Drain type | Differential-pressure drain |
| Bowl material | PC |
| Pressure gauge | Fitted — square, MPa scale |
| Reflux valve | Not fitted |
Specifications follow the official AirTAC G-series air-preparation data. The regulating band is set by the drain type: automatic and differential-pressure drains regulate 0.15 - 0.9 MPa, a manual drain regulates 0.05 - 0.9 MPa. Standard type, regulating 0.15 - 0.9 MPa (20 - 130 psi). The set has no separate bracket code — the two units couple together with their own mounting hardware. Flow curves, weight and outline dimensions are not published in our data set — ask us and we will confirm from the factory datasheet.
Model Code: AirTAC GFC200-06 Combination Unit (GFC20006F1W)
| GFC200 | G-series two-unit set, 200 body — sets the port range. |
|---|---|
| 06 | Port size PT1/8". This body offers 06 = PT1/8", 08 = PT1/4". |
| (blank) | Drain: Differential-pressure drain — this also sets the regulating band (0.15 - 0.9 MPa (20 - 130 psi)). |
| (blank) | Standard type. Blank is standard, L is the low-pressure type. |
| (blank) | Pressure gauge fitted (blank). |
| F | Gauge shape: Square. C is round, F is square. |
| 1 | Gauge scale: MPa. 1 is MPa, 2 is psi, 3 is bar. |
| W | Filtering grade 5 µm. Only 40 µm (blank) and 5 µm (W) exist. |
| (blank) | PT thread. PT is the default; G is BSPP and T is NPT. |
| (blank) | No reverse-flow valve (the default). |
Field order is size, port, drain, type, gauge, shape, scale, grade, thread, reflux — there is no bracket position on a combination set. Constituent units, orderable separately as spares: GFR200-06 filter regulator and GL200-06 lubricator.
Size Class & How It Differs From GC
- GFC200PT1/8" - PT1/4"
- GFC300PT1/4" - PT1/2"
- GFC400PT3/8" - PT1/2"
- GFC600PT3/4" - PT1"
A GFC is two units because filtering and regulating share one body. A GC is three separate units — filter, regulator and lubricator. Both filter, regulate and lubricate; the GFC is the shorter assembly, the GC keeps the filter and regulator serviceable as separate bodies.
| This model | GFC200 · PT1/8" · 5 µm |
|---|---|
| One size up | GFC300 |
| Three-unit equivalent | GC200-06 |
| Build order | Filter regulator first, lubricator last |
Where the AirTAC GFC200-06 Combination Unit (GFC20006F1W) Is Used
Laboratory instrument air
Conditioning shop air before it reaches bench-top laboratory instruments and small air-driven fixtures, where the 5 um element keeps fine particles away from sensitive pneumatic controls.
Precision valve protection
Protecting pilot-operated and precision pneumatic valves on a production machine: the 5 um element reduces fine contamination reaching the pilot stages while the regulator and lubricator condition the supply.
High-cycle packaging heads
Feeding high-cycle sealing and filling heads on a packaging machine, where clean, finely filtered and lubricated air supports the fast-cycling cylinders and valves throughout the run.
Is the AirTAC GFC200-06 Combination Unit (GFC20006F1W) the Right Set?
Size 200 with a 1/8 in PT port is the entry step of the G-series ladder; step up to 300, 400 or 600 when the port size or the air demand of the line calls for it. The defining choice on this code is the W filter grade: 5 um instead of the standard 40 um, for applications where finer particle protection matters. Drain choice still applies: differential-pressure drain (this code) works off the pressure drop across the element, while automatic and manual drain codes suit other line patterns. The regulator on this differential-drain set covers 0.15-0.9 MPa (20-130 psi) with the embedded square gauge on an MPa scale.
Threads can be ordered as PT (standard on this code), G (BSPP) or NPT, and the bracket is included unless a J code is specified. Because flow is published as curves and not a single rating, ask us to confirm sizing against your application before ordering - the finer element also has a different curve shape, which we can check for your duty on request.
Quick checklist
- ✓ Body size for your peak flow (PT1/8" here)
- ✓ Element 40 µm or 5 µm
- ✓ Drain sets the regulating band
- ✓ Gauge fitted, shape and scale
- ✓ Two-unit (GFC) or three-unit (GC) layout
- ✓ Oil mist acceptable downstream
Installation & Maintenance Notes
- check Install with the airflow arrow: filter regulator first, lubricator last.
- check Mount vertically, bowls down.
- check Keep inlet pressure at or below 1.0 MPa (145 psi).
- check Adjust only within 0.15 - 0.9 MPa (20 - 130 psi).
- check Drain condensate before the bowl fills; check the oil level.
- check Keep the set above freezing (-5 to +70 °C, unfreeze).
The PC bowls must not be cleaned with solvents — wipe them with a dry cloth. The lubricator adds an oil mist downstream, so if any branch must stay oil-free, take that branch off before the lubricator or use a GFR200-06 filter regulator on its own.
AirTAC GFC200-06 Combination Unit (GFC20006F1W) FAQ
AirTAC publishes G-series flow as curves, not as a single rated figure, so we do not quote one number here. Tell us your line pressure and air demand and we will confirm the sizing from the datasheet on request.
The standard 40 um element suits general actuator supply. The W code selects the 5 um element for finer particle protection, which suits instrument air, pilot-operated valves and similar duties. It is the same two-unit set otherwise - size 200, 1/8 in PT port, differential-pressure drain and MPa square gauge - and we can confirm the best grade for your application on request.
