Airtac GPR Precision Pressure Regulator GPR30008H
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR30008H Precision Air Pressure Regulator Specifications
- Model: GPR30008H (Industrial Series)
- Type: Precision pressure-reducing valve with gauge port
- Adjustment range: 0.05–0.85 MPa
- Maximum input pressure: 1.0 MPa
- Port size: PT1/4 (BSPP thread)
- Flow characteristics: Cv value 0.3
- Pressure gauge interface: G1/8 female thread
- Hysteresis: ≤0.02 MPa
- Operating temperature: -5℃ to 60℃
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 0.65 kg ±5%
- Dimensions: 50mm(W) × 50mm(D) × 83.5mm(H)
- Protection class: IP40 (Dust protected)
- Mounting orientation: Vertical ±15°
High-sensitivity pressure regulator featuring dual-chamber diaphragm design for stable output under fluctuating input pressures. Includes integrated locking knob with ±2% FS accuracy and 240° rotation range. The corrosion-resistant construction with built-in silencer minimizes pressure oscillation, making it ideal for precision pneumatic systems requiring steady air supply.
- Robotic end-effector pressure control
- Semiconductor manufacturing equipment
- Medical device pneumatic circuits
- Laser cutting machine air assist systems
- Laboratory analytical instrument gas control
Installation guidelines:
Install downstream of 5μm filter regulator. Allow 20mm clearance below adjustment knob for maintenance.
Perform initial calibration at 0.3MPa with flow demand. Drain condensate weekly via bottom venting screw.
- Max input pressure fluctuation: ±15% of set value
- Recommended service interval: 5,000 hours or 6 months
- Lubrication: ISO VG32 turbine oil mist (optional)
| Property | Property Value |
|---|---|
| sku | GPR30008H |
| Port Size | PT1/4 |
