Airtac GPR Precision Pressure Regulator GPR30008L
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR Series Precision Pressure Regulator GPR30008L Technical Details
- Model: GPR30008L (L-type locking knob version)
- Type: Precision pressure regulator with pressure gauge port
- Port size: PT1/4 (BSPP 1/4")
- Operating pressure range: 0.05–0.85 MPa
- Maximum input pressure: 1.0 MPa
- Pressure regulation accuracy: ±0.008 MPa
- Flow capacity: Cv 0.15 (Kv 0.13)
- Body material: Anodized aluminum alloy (ADC12)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 70℃ (non-freezing conditions)
- Weight: 0.6 kg ±5%
- Dimensions: 55mm(W) × 92mm(H) × 62mm(D)
- Gauge thread: R1/8 (optional M5 adapter included)
- Protection rating: IP40 (dust protected)
- Relief type: Built-in overflow function
High-sensitivity pressure regulator featuring dual-chamber diaphragm design for stable output under fluctuating input pressures. The L-type locking knob prevents accidental adjustment, with color-coded rotation direction (red ring for pressure increase). Includes dual-scale pressure gauge (0-1.0 MPa range) with kPa/psi graduations. Requires 5μm pre-filtering for optimal performance.
- Precision pneumatic tool pressure stabilization
- Semiconductor manufacturing equipment
- Medical gas pressure control systems
- Automated packaging line actuators
- Laboratory pneumatic instrument calibration
Installation protocol:
Mount vertically with arrow direction matching airflow. Allow 50mm clearance below gauge for visibility.
Lubricate threads with PTFE tape (not included). Perform initial pressure bleed before adjustment.
| Property | Property Value |
|---|---|
| sku | GPR30008L |
| Port Size | PT1/4 |
