Airtac GPR Precision Pressure Regulator GPR30008LJN
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR30008LJN Precision Pressure Regulator Specifications
- Model: GPR30008LJN
- Type: Precision pressure regulator with lock mechanism
- Port size: PT3/8 (BSPP thread)
- Operating pressure range: 0.05–0.85 MPa
- Maximum inlet pressure: 1.0 MPa
- Pressure gauge interface: R1/8 (optional gauge not included)
- Flow capacity: 3,000 NL/min (ANR)
- Accuracy: ±5% of set pressure
- Hysteresis: ≤0.01 MPa
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Weight: 0.68 kg (1.5 lbs)
- Dimensions: 98mm(H) × 70mm(W) × 70mm(D)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (hydrogenated nitrile)
- Pressure adjustment: Knob with ±7 full rotations
- Lock mechanism: Push-pull locking collar
High-sensitivity pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The integrated pressure lock prevents accidental setting changes, while the oversized diaphragm ensures quick response (≤0.3s). Includes dust-resistant filter screen (replaceable) and dual pressure gauge ports for system monitoring.
- Laser cutting machine gas pressure control
- Semiconductor manufacturing pneumatic systems
- Automated painting equipment pressure stabilization
- Industrial robot end-effector force regulation
- Medical oxygen concentrator systems
Installation note:
Mount vertically with arrow aligned to flow direction. Use 2.5Nm torque for port connections.
Lubricate threads with PTFE tape only. Perform weekly drain valve operation in humid environments.
| Property | Property Value |
|---|---|
| sku | GPR30008LJN |
| Port Size | PT1/4 |
