Airtac GPR Precision Pressure Regulator GPR30008M
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR30008M Precision Pressure Regulator Specifications
- Model: GPR30008M
- Type: Precision pressure-reducing valve with lockable handwheel
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–0.85 MPa
- Max inlet pressure: 1.5 MPa
- Pressure gauge interface: Rc1/8
- Flow characteristics: 1,500 Nl/min (ANR)
- Hysteresis: ≤0.02 MPa
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Seal material: NBR + PU hybrid diaphragm
- Weight: 0.52 kg ±3%
- Dimensions: 98mm(L) × 52mm(W) × 48mm(H)
- Protection rating: IP40 (dust-resistant)
- Vibration resistance: ≤1.5mm amplitude at 10–55Hz
High-accuracy pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The stainless steel spring and hybrid diaphragm ensure ≤±2% set pressure deviation. Includes a tamper-proof locking ring and integrated pressure gauge port. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Semiconductor wafer handling robotics
- Pharmaceutical blister packaging machines
- Laser cutting machine pneumatic circuits
- Automotive assembly line torque tools
- Food-grade pneumatic conveying systems
Installation protocol:
Mount vertically with arrow aligned to airflow direction. For pulsation-sensitive applications,
install 300mm downstream from quick exhaust valves. Lubricate adjustment screw monthly
with ISO VG32 pneumatic oil.
| Property | Property Value |
|---|---|
| sku | GPR30008M |
| Port Size | PT1/4 |
