Airtac GPR Precision Pressure Regulator GPR30008MG
2. Superior pressure and flow characteristics;
3. Flexible installation options: compatible with standalone mounting via integrated bracket or direct integration with existing GAF modular filtration units;
4. Available in high-pressure, medium-pressure, and low-pressure versions to suit diverse application requirements.
Category: Pressure Regulators | Brand: AirTAC | Series: GPR
AirTAC GPR30008MG Precision Pressure Regulator Technical Details
- Model: GPR30008MG
- Type: Pilot-operated precision regulator with gauge port
- Port size: 1/4" NPT (G1/8 optional)
- Pressure range: 0.05–0.85 MPa
- Maximum flow: 3000 NL/min
- Accuracy: ±0.008 MPa
- Adjustment knob: Lockable rotary dial with ±5° deadband
- Filter element: 40μm stainless steel mesh (replaceable)
- Hysteresis: ≤1.5% F.S.
- Operating temperature: -5℃ to 60℃ (no freeze)
- Body material: Anodized aluminum alloy
- Seal material: HNBR with PTFE coating
- Weight: 480g ±5%
- Dimensions: 78mm(L) × 52mm(W) × 98mm(H)
- Pressure gauge interface: M5×0.8 threaded
- Relief mechanism: Built-in overflow vent
Industrial-grade pressure regulator featuring dual-chamber design for stable output under fluctuating input pressures. The chrome-plated diaphragm ensures ≤0.5% pressure creep during standby. Includes tamper-proof adjustment lock and visible pressure scale (0-1.0 MPa range). Compatible with ISO 8573-1:2010 [7:4:4] compressed air standards.
- Pneumatic actuator pressure stabilization in assembly lines
- Medical gas pressure control systems
- Packaging machinery tension regulation
- Semiconductor manufacturing equipment
- CNC machine tool pneumatic circuits
Installation guidelines:
Mount vertically with arrow aligned to airflow direction. Maintain minimum
30cm upstream straight piping. Drain condensate weekly via bottom port.
Requires 5-10μm pre-filter for optimal diaphragm life.
| Property | Property Value |
|---|---|
| sku | GPR30008MG |
| Port Size | PT1/4 |
