Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD16X10S
$38.37
Regular price
$45.87
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MACD16X10S
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MACD Series Double Rod Cushioned Stainless Steel Miniature Cylinders
1. Complies with in-house enterprise standards;
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
Installation note:
Align rod ends within 0.2mm perpendicular tolerance. Use anti-vibration
washers in high-cycle applications (>1 million cycles). Lubricate every
3 months in continuous operation.
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD16X10S Double Rod Cushioned Stainless Steel Mini Cylinder Specifications
- Model: MACD16X10S
- Type: Double rod cylinder with adjustable cushioning
- Bore size: 16mm (0.63")
- Stroke: 10mm (0.39") [Customizable up to 100mm]
- Cushion type: Adjustable rubber buffers at both ends
- Material: Stainless steel (SUS304 barrel, SUS303 rods)
- Operating pressure: 0.05–1.0 MPa (7–145 psi)
- Temperature range: -20℃ to 150℃ (-4°F to 302°F)
- Port size: M5x0.8 (Standard) with NPT1/8 adapter optional
- Piston speed: 50–800 mm/s (with cushioning)
- Mounting style: Basic front flange (NFAB type)
- Weight: 210g (0.46 lbs)
- Dimensions:
- Body length: 90mm (3.54")
- Extended length: 100mm (3.94")
- Width: 34mm (1.34")
- Height: 34mm (1.34")
Corrosion-resistant stainless steel construction with dual rod synchronization ensures precise linear motion in harsh environments. Features multi-layer sealing system (PU + metal scraper) for IP67 protection. Requires 0.3μm filtered air and ISO VG32 lubricant for optimal performance.
Typical Applications:
- Food processing equipment (washdown environments)
- Pharmaceutical tablet pressing machines
- Semiconductor wafer handling robots
- Marine automation systems
- High-temperature curing oven mechanisms
Installation note:
Align rod ends within 0.2mm perpendicular tolerance. Use anti-vibration
washers in high-cycle applications (>1 million cycles). Lubricate every
3 months in continuous operation.
| Property | Property Value |
|---|---|
| sku | MACD16X10S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
